Product 78BD9060-2 - Web Catalogo

Description: Brake disc
Axe: Front
No. of Pieces: 2
Barcode: 8424073149244
Url: https://catalogonuevo.icerbrakes.com/Producto/Details?idProducto=78BD9060-2
Weight (gr.): 13404

R90 Homologation: 90R-02C0452/0118
Measures: Ø280x25x42
: Brake Disc Type: Vented; Minimum thickness [mm]: 22; Hole Arrangement/Number: 5; Bolt Hole Circle Ø [mm]: 110; Wheel Hub Diameter [mm]: 70

Reference applications

Brand	OE Reference
OPEL	5 69 060
VAUXHALL	90 539 466
VAUXHALL	91 176 78

Maker	Cross reference
ATE	24.0125-0131.1
ATE	425131
BENDIX-ROULUNDS	510291
BOSCH	0 986 478 883
BREMBO	09.7629.10
DELPHI LOCKHEED	BG3405
LETEC	LBG026V
NECTO	WN1064
ROAD HOUSE	6584.10
SANLI	SL32429
TRW	DF4048

CHEVROLET

ASTRA () Estate 09/1994-12/2011

Vehicle	Engine	Fuel	Date	CC	KW	CV	Traction
1.8 GLS		1	08/2002-12/2011	1796	81	110	1
2.0	X 20 XEV	1	10/1999-07/2002	1998	94	128	1
2.0	C 20 SEL	1	08/2002-07/2005	1998	100	136	1
2.2		1	01/2001-12/2003	2198	108	147	1

ASTRA () Hatchback 09/1998-12/2011

Vehicle	Engine	Fuel	Date	CC	KW	CV	Traction
1.8 (08, 48)	C 18 NE C 18 YE LC5(110CUL4)	1	09/1998-12/2011	1796	81	110	1
2.0	C 20 SEJ	1	03/1999-07/2002	1998	82	112	1
2.0	LE4(122CUL4)	1	08/2002-12/2011	1998	85	116	1
2.0	X 20 XEV	1	03/1999-07/2002	1998	94	128	1
2.0 (08, 48)	L34(122CUL4)	1	08/2002-07/2005	1998	100	136	1
2.2	Z 22 SE	1	08/2000-08/2004	2198	108	147	1
1.7 Di	Y 17 DT	2	08/2000-08/2003	1686	55	75	1
2.0 DTI	LD1	2	08/2002-12/2011	1995	74	101	1

ASTRA () Saloon 10/1998-12/2011

Vehicle	Engine	Fuel	Date	CC	KW	CV	Traction
1.8	2H9	1	08/2002-06/2005	1796	92	125	1
1.8 Flexfuel	C 18 NE C 18 YE	1	03/1999-12/2011	1796	81	110	1
2.0 GL	LE4(122CUL4)	1	10/1998-07/2002	1998	82	112	1
2.0 GL	LE4(122CUL4)	1	08/2002-12/2011	1998	85	116	1
2.0 GLS	X 20 XEV	1	03/1999-07/2002	1998	94	128	1
2.0 GLS (69)	C 20 SEL L34(122CUL4)	1	08/2002-12/2011	1998	100	136	1
2.0 DTi GLS	LD1	2	08/2002-12/2011	1995	74	101	1

VIVA () Saloon 09/2003-03/2008

Vehicle	Engine	Fuel	Date	CC	KW	CV	Traction
1.8		1	09/2003-03/2008	1796	90	122	1
1.8	2H9	1	09/2003-03/2008	1796	92	125	1

ZAFIRA / NABIRA (F75) MPV 02/1999-12/2012

Vehicle	Engine	Fuel	Date	CC	KW	CV	Traction
1.8	C 18 YE	1	02/1999-07/2001	1796	81	110	1
2.0	LE4(122CUL4)	1	04/2001-07/2004	1998	85	116	1
2.0	X 20 XE	1	08/2004-12/2012	1998	89	121	1
2.0	C 20 SEL L34(122CUL4)	1	04/2001-07/2012	1998	100	136	1
2.2		1	04/2001-07/2004	2198	91	124	1
2.2	Z 22 YH	1	09/2005-12/2006	2198	110	150	1

OPEL

ASTRA G (T98) Hatchback 02/1998-12/2009

Vehicle	Engine	Fuel	Date	CC	KW	CV	Traction
1.6 (F08, F48)	Z 16 XEP	1	11/2002-01/2005	1598	76	103	1
1.6 16V (F08, F48)	C 16 SEL X 16 XEL Z 16 XE	1	02/1998-01/2005	1598	74	101	1
1.8 (F08, F48)		1	02/2003-01/2004	1796	81	110	1
1.8 16V (F08, F48)	X 18 XE1	1	02/1998-09/2000	1796	85	116	1
1.8 16V (F08, F48)	Z 18 XE	1	09/2000-01/2005	1796	92	125	1
2.0 16V (F08, F48)	X 20 XEV	1	02/1998-01/2005	1998	100	136	1
2.2 16V (F08, F48)	Z 22 SE	1	06/2000-01/2005	2198	108	147	1
1.6 LPG (F08, F48)	X 16 XEL Z 16 XE	18	03/1998-01/2005	1598	74	101	1
2.0 DI (F08, F48)	X 20 DTL Y 20 DTL	2	02/1998-01/2005	1995	60	82	1
2.0 DTI 16V (F08, F48)	Y 20 DTH	2	08/1999-01/2005	1995	74	101	1
2.2 DTI (F08, F48)	Y 22 DTR	2	09/2002-01/2005	2172	86	117	1
2.2 DTI (F08, F48)	Y 22 DTR	2	09/2002-01/2005	2172	92	125	1

ASTRA G (T98) Estate 02/1998-07/2005

Vehicle	Engine	Fuel	Date	CC	KW	CV	Traction
1.6 (F35)	Z 16 SE	1	09/2000-07/2004	1598	62	84	1
1.6 (F35)	Z 16 XEP	1	12/2002-05/2004	1598	76	103	1
1.6 16V (F35)	X 16 XEL Z 16 XE	1	02/1998-07/2004	1598	74	101	1
1.8		1	02/2003-07/2004	1796	81	110	1
1.8 16V (F35)	X 18 XE1	1	02/1998-09/2000	1796	85	116	1
1.8 16V (F35)	Z 18 XE	1	09/2000-07/2004	1796	92	125	1
2.0 16V (F35)	X 20 XEV	1	02/1998-07/2004	1998	100	136	1
2.2 16V (F35)	Z 22 SE	1	03/2001-07/2004	2198	108	147	1
1.6 CNG (F35)	Z 16 YNG	16	03/2003-07/2004	1598	71	97	1
2.0 DI (F35)	X 20 DTL Y 20 DTL	2	02/1998-07/2004	1995	60	82	1
2.0 DTI 16V (F35)	Y 20 DTH	2	08/1999-07/2004	1995	74	101	1
2.2 DTI (F35)	Y 22 DTR	2	09/2002-07/2004	2172	86	117	1
2.2 DTI (F35)	Y 22 DTR	2	09/2002-07/2004	2172	92	125	1

ASTRA G (T98) Saloon 03/1998-12/2009

Vehicle	Engine	Fuel	Date	CC	KW	CV	Traction
1.6 (F69)	Z 16 XEP	1	12/2002-12/2009	1598	76	103	1
1.6 16V (F69)	X 16 XEL Z 16 XE	1	09/1998-01/2005	1598	74	101	1
1.8		1	02/2003-01/2005	1796	81	110	1
1.8 16V (F69)	X 18 XE1	1	09/1998-09/2000	1796	85	116	1
1.8 16V (F69)	Z 18 XE	1	06/2000-01/2005	1796	92	125	1
2.0 16V (F69)	X 20 XEV	1	09/1998-01/2005	1998	100	136	1
2.2 16V (F69)	Z 22 SE	1	03/2001-01/2005	2198	108	147	1
1.6 LPG (F69)	X 16 XEL Z 16 XE	18	06/2002-01/2005	1598	74	101	1
2.0 DI (F69)	X 20 DTL Y 20 DTL	2	09/1998-01/2005	1995	60	82	1
2.0 DTI 16V (F69)	Y 20 DTH	2	08/1999-01/2005	1995	74	101	1
2.2 DTI (F69)	Y 22 DTR	2	09/2002-01/2005	2172	86	117	1
2.2 DTI (F69)	Y 22 DTR	2	09/2002-01/2005	2172	92	125	1

ASTRA G (F70) Estate Van 09/1998-04/2005

Vehicle	Engine	Fuel	Date	CC	KW	CV	Traction
2.0 DI (F70)	X 20 DTL Y 20 DTL	2	01/1999-04/2005	1995	60	82	1
2.0 DTI (F70)	Y 20 DTH	2	09/2000-04/2005	1995	74	101	1

ASTRA G (T98) Coupe 03/2000-06/2006

Vehicle	Engine	Fuel	Date	CC	KW	CV	Traction
1.6 16V (F07)	Z 16 XE	1	03/2000-05/2005	1598	74	101	1
1.6 16V (F07)	Z 16 XEP	1	03/2000-05/2005	1598	76	103	1
1.8 16V (F07)	X 18 XE1	1	03/2000-10/2000	1796	85	116	1
1.8 16V (F07)	Z 18 XE	1	09/2000-05/2005	1796	92	125	1
2.2 16V (F07)	Z 22 SE	1	09/2000-05/2005	2198	108	147	1
2.2 DTI (F07)	Y 22 DTR	2	09/2002-05/2005	2172	92	125	1

ASTRA G (T98) Convertible 03/2001-10/2005

Vehicle	Engine	Fuel	Date	CC	KW	CV	Traction
1.6 (F67)	Z 16 XEP	1	01/2003-10/2005	1598	76	103	1
1.6 16V (F67)	Z 16 XE	1	03/2001-10/2005	1598	74	101	1
1.8 16V (F67)	Z 18 XE	1	03/2001-10/2005	1796	92	125	1
2.2 16V (F67)	Z 22 SE	1	03/2001-10/2005	2198	108	147	1
2.2 DTI (F67)	Y 22 DTR	2	09/2002-10/2005	2172	92	125	1

ASTRA H (A04) Hatchback 01/2004-05/2014

Vehicle	Engine	Fuel	Date	CC	KW	CV	Traction
1.8 (L48)	Z 18 XE	1	01/2004-10/2010	1796	92	125	1
1.8 (L48)	A 18 XER Z 18 XER	1	01/2006-10/2010	1796	103	140	1
1.3 CDTI (L48)	Z 13 DTH	2	08/2005-10/2010	1248	66	90	1
1.7 CDTI (L48)	Z 17 DTL	2	03/2004-10/2010	1686	59	80	1
1.7 CDTI (L48)	Z 17 DTH	2	03/2004-10/2010	1686	74	100	1
1.7 CDTI (L48)	A 17 DTJ Z 17 DTJ	2	02/2007-05/2014	1686	81	110	1
1.9 CDTI (L48)	Z 19 DTL	2	09/2005-10/2010	1910	74	100	1

ASTRA H (L70) Estate Van 02/2004-10/2014

Vehicle	Engine	Fuel	Date	CC	KW	CV	Traction
1.4 EcoTec (L70)	Z 14 XEP	1	12/2004-12/2012	1364	66	90	1
1.6 EcoTec (L70)	Z 16 XEP	1	02/2004-11/2004	1598	76	103	1
1.6 EcoTec (L70)	Z 16 XER	1	10/2006-12/2010	1598	85	116	1
1.3 CDTI (L70)	Z 13 DTH	2	08/2005-10/2010	1248	66	90	1
1.7 CDTI (L70)	Z 17 DTL	2	12/2004-07/2007	1686	59	80	1
1.7 CDTI (L70)	Z 17 DTH	2	03/2004-10/2010	1686	74	101	1
1.7 CDTI (L70)	A 17 DTJ Z 17 DTJ	2	02/2007-10/2014	1686	81	110	1
1.7 CDTI (L70)	A 17 DTR Z 17 DTR	2	02/2007-10/2010	1686	92	125	1
1.9 CDTI (L70)	Z 19 DTL	2	08/2005-12/2012	1910	74	101	1
1.9 CDTI (L70)	Z 19 DT	2	09/2005-10/2010	1910	88	120	1
1.9 CDTI (L70)	Z 19 DTH	2	09/2004-10/2010	1910	110	150	1
1.9 CDTI 16V (L70)	Z 19 DTJ	2	08/2004-10/2010	1910	88	120	1

ASTRA H (A04) Estate 08/2004-05/2014

Vehicle	Engine	Fuel	Date	CC	KW	CV	Traction
1.4 (L35)	Z 14 XEL	1	08/2004-10/2010	1364	55	75	1
1.6 (L35)	A 16 XER Z 16 XER	1	12/2006-05/2014	1598	85	116	1
1.8 (L35)	Z 18 XE	1	08/2004-10/2010	1796	92	125	1
1.8 (L35)	A 18 XER Z 18 XER	1	08/2005-05/2014	1796	103	140	1
1.4 LPG (L35)	Z 14 XEP	18	08/2009-10/2010	1364	66	90	1
1.6 LPG (L35)	Z 16 XER	18	08/2009-10/2010	1598	85	116	1
1.3 CDTI (L35)	Z 13 DTH	2	08/2005-10/2010	1248	66	90	1
1.7 CDTI (L35)	Z 17 DTL	2	08/2004-10/2010	1686	59	80	1
1.7 CDTI (L35)	Z 17 DTH	2	08/2004-10/2010	1686	74	101	1
1.7 CDTI (L35)	A 17 DTJ Z 17 DTJ	2	02/2007-05/2014	1686	81	110	1

ASTRA H GTC (A04) Hatchback 03/2005-10/2010

Vehicle	Engine	Fuel	Date	CC	KW	CV	Traction
1.4 (L08)	Z 14 XEL	1	03/2005-10/2010	1364	55	75	1
1.8 (L08)	Z 18 XE	1	03/2005-10/2010	1796	92	125	1
1.8 (L08)	Z 18 XER	1	01/2006-10/2010	1796	103	140	1
1.3 CDTI (L08)	Z 13 DTH	2	04/2005-10/2010	1248	66	90	1
1.7 CDTi (L08)	Z 17 DTL	2	03/2005-10/2010	1686	59	80	1
1.7 CDTi (L08)	Z 17 DTH	2	03/2005-10/2010	1686	74	101	1
1.7 CDTi (L08)	A 17 DTJ Z 17 DTJ	2	02/2007-10/2010	1686	81	110	1

ASTRA H TwinTop (A04) Convertible 09/2005-10/2010

Vehicle	Engine	Fuel	Date	CC	KW	CV	Traction
1.4 (L67)	Z 14 XEP	1	10/2005-10/2010	1364	66	90	1
1.8 (L67)	Z 18 XE	1	09/2005-10/2010	1796	92	125	1
1.8 (L67)	A 18 XER Z 18 XER	1	09/2005-10/2010	1796	103	140	1

ASTRA H CLASSIC (A04) Estate 12/2006-

Vehicle	Engine	Fuel	Date	CC	KW	CV	Traction
1.4 (L35)	Z 14 XEP	1	01/2009-	1364	66	90	1
1.6 (L35)	Z 16 XER	1	12/2006-05/2014	1598	85	116	1
1.8 (L35)	Z 18 XER	1	01/2012-05/2014	1796	103	140	1
1.7 CDTI (L35)	Z 17 DTJ	2	01/2009-	1686	81	110	1

ASTRA H (A04) Saloon 02/2007-05/2014

Vehicle	Engine	Fuel	Date	CC	KW	CV	Traction
1.4 (L69)	Z 14 XEP	1	02/2007-06/2010	1364	66	90	1
1.6 (L69)	Z 16 XEP	1	02/2007-06/2010	1598	77	105	1
1.8 (L69)	A 18 XER Z 18 XER	1	02/2007-09/2012	1796	103	140	1
1.3 CDTi (L69)	Z 13 DTH	2	02/2007-10/2010	1248	66	90	1
1.7 CDTi (L69)	Z 17 DTH	2	02/2007-10/2010	1686	74	101	1
1.7 CDTi (L69)	Z 17 DTJ	2	02/2007-05/2014	1686	81	110	1

ASTRA H CLASSIC (A04) Saloon 02/2007-

Vehicle	Engine	Fuel	Date	CC	KW	CV	Traction
1.6 (L69)	Z 16 XER	1	01/2009-05/2014	1598	85	116	1
1.8 (L69)	Z 18 XER	1	02/2007-09/2012	1796	103	140	1
1.7 CDTi (L69)	Z 17 DTJ	2	01/2009-	1686	81	110	1
1.7 CDTi (L69)	A 17 DTR Z 17 DTR	2	01/2009-	1686	92	125	1

ASTRA H CLASSIC (A04) Hatchback 01/2009-

Vehicle	Engine	Fuel	Date	CC	KW	CV	Traction
1.4 (L48)	Z 14 XEP	1	01/2009-	1364	66	90	1
1.3 CDTI (L48)	Z 13 DTH	2	01/2009-	1248	66	90	1
1.7 CDTI (L48)	A 17 DTJ Z 17 DTJ	2	01/2009-	1686	81	110	1

COMBO C () Box Body/MPV 10/2001-

Vehicle	Engine	Fuel	Date	CC	KW	CV	Traction
1.7 CDTI 16V	Z 17 DTH	2	12/2004-	1686	74	101	1

COMBO C Tour () MPV 10/2001-

Vehicle	Engine	Fuel	Date	CC	KW	CV	Traction
1.7 CDTI 16V	Z 17 DTH	2	07/2004-12/2011	1686	74	101	1

MERIVA A (X03) MPV 05/2003-05/2010

Vehicle	Engine	Fuel	Date	CC	KW	CV	Traction
1.4 16V Twinport LPG (E75)	Z 14 XEP	18	07/2004-05/2010	1364	66	90	1
1.7 CDTI (E75)	Z 17 DT Z 17 DTH	2	09/2003-05/2010	1686	74	100	1
1.7 CDTI (E75)	Z 17 DTR	2	09/2006-05/2010	1686	92	125	1

MERIVA B (S10) MPV 06/2010-

Vehicle	Engine	Fuel	Date	CC	KW	CV	Traction
1.4 (75)	A 14 NEL B 14 NEL	1	06/2010-03/2017	1364	88	120	1
1.4 (75)	A 14 XER B 14 XER	1	06/2010-03/2017	1398	74	100	1
1.4 LPG (75)	A 14 NEL B 14 NEL	18	06/2011-03/2017	1364	88	120	1
1.3 CDTI (75)	A 13 DTC	2	06/2010-10/2013	1248	55	75	1
1.3 CDTI (75)	A 13 DTE	2	06/2010-11/2014	1248	70	95	1
1.7 CDTI (75)	A 17 DT	2	06/2010-01/2017	1686	74	100	1
1.7 CDTI (75)	A 17 DTC A 17 DTI	2	06/2010-06/2015	1686	81	110	1

MERIVA B VAN (S10) Box Body/MPV 06/2010-03/2017

Vehicle	Fuel	Date	CC	KW	CV	Traction
1.4 ECOTEC (75)	1	01/2013-03/2017	1398	74	101	1
1.3 CDTI (75)	2	01/2013-11/2014	1248	70	95	1
1.7 CDTI (75)	2	01/2013-01/2017	1686	74	101	1
1.7 CDTI (75)	2	01/2013-10/2013	1686	81	110	1

ZAFIRA A (T98) MPV 04/1999-06/2006

Vehicle	Engine	Fuel	Date	CC	KW	CV	Traction
1.6		1	09/2002-06/2005	1598	70	95	1
1.6 (F75)	Z 16 XE	1	10/2003-06/2005	1598	76	103	1
1.6 16V (F75)	X 16 XEL Z 16 XE	1	04/1999-06/2005	1598	74	101	1
1.8		1	02/2003-06/2005	1796	81	110	1
1.8 16V (F75)	X 18 XE1	1	04/1999-09/2000	1796	85	116	1
1.8 16V (F75)	Z 18 XE	1	09/2000-06/2005	1796	92	125	1
2.2 16V (F75)	Z 22 SE	1	09/2000-06/2005	2198	108	147	1
1.6 CNG (F75)	Z 16 YNG	16	09/2001-06/2005	1598	71	97	1
1.6 LPG (F75)	X 16 XEL Z 16 XE	18	04/1999-06/2005	1598	74	101	1
1.6 LPG (F75)	Z 16 XEP	18	10/2003-06/2005	1598	76	103	1
2.0 DI (F75)		2	07/1999-06/2000	1995	63	86	1
2.0 DI 16V (F75)	X 20 DTL Y 20 DTL	2	07/1999-06/2005	1995	60	82	1
2.0 DTI 16V (F75)	Y 20 DTH	2	09/2000-06/2005	1995	74	101	1
2.2 DTI 16V (F75)	Y 22 DTR	2	01/2002-06/2005	2172	86	117	1
2.2 DTI 16V (F75)	Y 22 DTR	2	01/2002-06/2005	2172	92	125	1

ZAFIRA B (A05) Box Body/MPV 07/2005-

Vehicle	Engine	Fuel	Date	CC	KW	CV	Traction
1.8 VAN (M75)	A 18 XER Z 18 XER	1	07/2005-04/2015	1796	103	140	1

ZAFIRA / ZAFIRA FAMILY B (A05) MPV 07/2005-

Vehicle	Engine	Fuel	Date	CC	KW	CV	Traction
1.6 (M75)	Z 16 XE1 Z 16 XEP	1	07/2005-09/2012	1598	77	105	1
1.6 (M75)	A 16 XER Z 16 XER	1	01/2008-04/2015	1598	85	115	1
1.8 (M75)	A 18 XER Z 18 XER	1	07/2005-04/2015	1796	103	140	1
1.6 CNG (M75)	Z 16 YNG	16	07/2005-04/2015	1598	69	94	1
1.8 LPG (M75)	Z 18 XER	18	07/2009-04/2015	1796	103	140	1
1.6 FlexFuel (M75)	Z 16 XER	19	08/2008-12/2012	1598	85	116	1

VAUXHALL

ASTRAVAN Mk IV (G) (T98) Estate Van 01/1993-08/2006

Vehicle	Engine	Fuel	Date	CC	KW	CV	Traction
1.6 Dualfuel 16V	Z 16 XEP	18	10/2004-12/2005	1598	77	105	1
1.7 CDTi	Z 17 DTL	2	07/2003-08/2006	1686	59	80	1
2.0 DI	X 20 DTL Y 20 DTL	2	08/1998-08/2006	1995	60	82	1
2.0 DTI	Y 20 DTH	2	04/2004-08/2006	1995	74	100	1

ASTRA Mk IV (G) (T98) Hatchback 02/1998-05/2005

Vehicle	Engine	Fuel	Date	CC	KW	CV	Traction
1.6 (F08, F48)	Z 16 XEP	1	12/2002-05/2005	1598	76	103	1
1.6 16V (F08, F48)	X 16 XEL Z 16 XE	1	02/1998-05/2005	1598	74	101	1
1.8 16V (F08, F48)	X 18 XE1	1	02/1998-09/2000	1796	85	116	1
1.8 16V (F08, F48)	Z 18 XE	1	09/2000-05/2005	1796	92	125	1
2.0 (F08, F48)		1	10/1999-08/2000	1998	118	160	1
2.0 16V (F08)	X 20 XEV	1	02/1998-05/2005	1998	100	136	1
2.0 SRI Turbo (F08)	Z 20 LET	1	11/2001-05/2005	1998	141	192	1
2.2 16V (F08, F48)	Z 22 SE	1	03/2001-05/2005	2198	108	147	1
1.8 16V Dualfuel (F08, F48)	Z 18 XE	18	09/2002-05/2005	1796	87	118	1
1.8 16V Dualfuel (F08, F48)	Z 18 XE	18	07/2002-12/2003	1796	92	125	1
2.0 DI (F48)	X 20 DTL Y 20 DTL	2	02/1998-05/2005	1995	60	82	1
2.0 DTI 16V (F48)	Y 20 DTH	2	08/1999-05/2005	1995	74	101	1

ASTRA Mk IV (G) (T98) Saloon 02/1998-05/2005

Vehicle	Engine	Fuel	Date	CC	KW	CV	Traction
1.6 16V	X 16 XEL Z 16 XE	1	09/1998-05/2005	1598	74	101	1
1.8 16V	X 18 XE1	1	02/1998-07/2004	1796	85	116	1
1.8 16V	Z 18 XE	1	02/1998-07/2004	1796	92	125	1
2.0 16V	X 20 XEV	1	09/1998-05/2005	1998	100	136	1
2.2 16V		1	03/2001-05/2005	2198	108	147	2
1.8 16V Dualfuel	Z 18 XE	18	02/1998-07/2004	1796	87	118	1
1.8 16V Dualfuel		18	07/2002-12/2003	1796	92	125	1
2.0 DI	X 20 DTL Y 20 DTL	2	02/1998-07/2004	1995	60	82	1
2.0 DTI 16V	Y 20 DTH	2	02/1998-07/2004	1995	74	101	1

ASTRA Mk IV (G) (T98) Estate 02/1998-05/2005

Vehicle	Engine	Fuel	Date	CC	KW	CV	Traction
1.4 16V	X 14 XE Z 14 XE	1	02/1998-05/2005	1389	66	90	1
1.6	X 16 SZR	1	03/1998-04/2004	1598	55	75	1
1.6	Z 16 SE	1	03/1998-04/2004	1598	62	84	1
1.6	Z 16 XEP	1	12/2002-05/2005	1598	76	103	1
1.6 16V	X 16 XEL Z 16 XE	1	03/1998-04/2004	1598	74	101	1
1.8 16V	X 18 XE1	1	02/1998-08/2000	1796	85	116	1
1.8 16V	Z 18 XE	1	09/2000-05/2005	1796	92	125	1
2.0 16V		1	02/1998-05/2005	1998	100	136	1
2.2 16V	Z 22 SE	1	03/2001-05/2005	2198	108	147	1
1.6 Dualfuel	Z 16 SE	18	03/1998-04/2004	1598	63	85	1
1.8 16V Dualfuel	Z 18 XE	18	09/2002-05/2005	1796	87	118	1
1.8 16V Dualfuel	Z 18 XE	18	07/2002-12/2003	1796	92	125	1
2.0 DI	X 20 DTL Y 20 DTL	2	03/1998-04/2004	1995	60	82	1
2.0 DTI 16V	Y 20 DTH	2	03/1998-04/2004	1995	74	101	1

ASTRA Mk IV (G) (T98) Coupe 03/2000-08/2005

Vehicle	Engine	Fuel	Date	CC	KW	CV	Traction
1.6 16V	Z 16 XEP	1	03/2000-08/2005	1598	76	103	1
1.8 16V	X 18 XE1	1	03/2000-08/2005	1796	85	115	1
1.8 16V	Z 18 XE	1	09/2000-08/2005	1796	92	125	1
2.0		1	08/2002-05/2005	1998	147	199	1
2.0 16V Turbo	Z 20 LET	1	09/2000-08/2005	1998	140	190	1
2.2 16V	Z 22 SE	1	03/2000-08/2005	2198	108	147	1
1.8 16V Dualfuel	Z 18 XE	18	09/2002-08/2005	1796	87	118	1
1.8 16V Dualfuel	Z 18 XE	18	07/2002-08/2004	1796	92	125	1

ASTRA Mk IV (G) (T98) Convertible 03/2001-10/2005

Vehicle	Engine	Fuel	Date	CC	KW	CV	Traction
1.6 16V	Z 16 XE	1	03/2001-10/2005	1598	74	101	1
1.8 16V	Z 18 XE	1	03/2001-10/2005	1796	92	125	1
2.0	Z 20 LET	1	09/2002-10/2005	1998	147	200	1
2.0 Turbo	Z 20 LET	1	03/2002-10/2005	1998	141	192	1
2.2 16V	Z 22 SE	1	03/2001-10/2005	2198	108	147	1

ASTRA Mk V (H) (A04) Hatchback 01/2004-03/2011

Vehicle	Engine	Fuel	Date	CC	KW	CV	Traction
1.8 (L48)	Z 18 XE	1	01/2004-05/2009	1796	92	125	1
1.8 (L48)	A 18 XER Z 18 XER	1	01/2004-05/2009	1796	103	140	1
1.3 CDTI (L48)	Z 13 DTH	2	01/2004-05/2009	1248	66	90	1
1.7 CDTI (L48)	Z 17 DTL	2	01/2004-05/2009	1686	59	80	1
1.7 CDTI (L48)	Z 17 DTH	2	01/2004-05/2009	1686	74	100	1
1.7 CDTI (L48)	A 17 DTJ Z 17 DTJ	2	01/2004-03/2011	1686	81	110	1
1.7 TD		2	01/2004-05/2009	1686	79	108	2

ASTRA Mk V (H) (A04) Estate 08/2004-10/2012

Vehicle	Engine	Fuel	Date	CC	KW	CV	Traction
1.6 (L35)	A 16 LET Z 16 LET	1	08/2004-03/2009	1598	132	180	1
1.8 (L35)	Z 18 XE	1	10/2004-03/2009	1796	92	125	1
1.8 (L35)	A 18 XER Z 18 XER	1	12/2005-10/2010	1796	103	140	1
1.3 CDTI (L35)	Z 13 DTH	2	08/2004-03/2009	1248	66	90	1
1.7 CDTI (L35)	Z 17 DTH	2	08/2004-03/2009	1686	74	100	1
1.7 CDTI (L35)	A 17 DTJ Z 17 DTJ	2	08/2004-10/2012	1686	81	110	1
1.7 TD		2	08/2004-03/2009	1686	79	108	2

ASTRA Mk V (H) Sport Hatch (A04) Hatchback 02/2005-11/2010

Vehicle	Engine	Fuel	Date	CC	KW	CV	Traction
1.4 i 16V (L08)	Z 14 XEP	1	03/2005-11/2010	1364	66	90	1
1.6 i 16V (L08)	A 16 XER Z 16 XER	1	12/2006-11/2010	1598	85	116	1
1.8 (L08)	Z 18 XE	1	02/2005-11/2010	1796	92	125	1
1.8 i 16V (L08)	A 18 XER Z 18 XER	1	03/2007-11/2010	1796	103	140	1
1.3 CDTI (L08)	Z 13 DTH	2	04/2005-11/2010	1248	66	90	1
1.7 CDTi (L08)	Z 17 DTH	2	02/2005-11/2010	1686	74	100	1
1.7 CDTi (L08)	A 17 DTJ Z 17 DTJ	2	02/2007-11/2009	1686	81	110	1

ASTRAVAN Mk V (H) (A04) Estate Van 03/2005-

Vehicle	Engine	Fuel	Date	CC	KW	CV	Traction
1.4 i	Z 14 XEP	1	03/2005-	1364	66	90	1
1.6	Z 16 XE1 Z 16 XEP	1	03/2005-	1598	76	103	1
1.3 CDTi	Z 13 DTH	2	08/2005-	1248	66	90	1
1.7 CDTi	Z 17 DTH	2	03/2005-11/2011	1686	74	101	1
1.7 CDTi	A 17 DTJ Z 17 DTJ	2	06/2011-12/2013	1686	81	110	1

ASTRA Mk V (H) TwinTop (A04) Convertible 09/2005-08/2011

Vehicle	Engine	Fuel	Date	CC	KW	CV	Traction
1.6		1	10/2006-11/2010	1598	132	179	1
1.6 (L67)	Z 16 XEP	1	09/2005-11/2010	1598	77	105	1
1.6 i 16V (L67)	A 16 XER Z 16 XER	1	10/2006-08/2011	1598	85	116	1
1.8 (L67)	A 18 XER Z 18 XER	1	05/2008-11/2010	1796	103	140	1

COMBO Mk II (C) (F25) Box Body/MPV 09/2001-02/2012

Vehicle	Engine	Fuel	Date	CC	KW	CV	Traction
1.7 CDTI 16V	Z 17 DTH	2	12/2004-11/2011	1686	74	101	1

COMBO TOUR Mk II (C) (F25) MPV 09/2001-02/2012

Vehicle	Engine	Fuel	Date	CC	KW	CV	Traction
1.7 CDTI 16V	Z 17 DTH	2	12/2004-09/2010	1686	74	101	1

MERIVA Mk I (A) (X03) MPV 01/2003-06/2010

Vehicle	Engine	Fuel	Date	CC	KW	CV	Traction
1.3 CDTi	Y 13 DT Z 13 DT	2	04/2005-06/2010	1248	51	69	1
1.7 CDTi	Z 17 DTH	2	09/2003-08/2005	1686	74	100	1
1.7 CDTi		2	08/2006-06/2010	1686	92	125	2
1.7 DTI	Y 17 DT	2	06/2003-06/2010	1686	55	75	1

MERIVA Mk II (B) (S10) MPV 06/2010-

Vehicle	Engine	Fuel	Date	CC	KW	CV	Traction
1.4	A 14 NEL B 14 NEL	1	06/2010-	1364	88	120	1
1.4	A 14 XER B 14 XER	1	06/2010-	1398	74	101	1
1.4 LPG	A 14 NEL	18	06/2011-	1364	88	120	1
1.3 CDTi	A 13 DTC	2	06/2010-	1248	55	75	1
1.3 CDTi	A 13 DTE	2	06/2010-	1248	70	95	1
1.7 CDTi	A 17 DT	2	06/2010-	1686	74	101	1
1.7 CDTi	A 17 DTC A 17 DTI	2	06/2010-	1686	81	110	1
1.7 CDTi	A 17 DTS	2	06/2010-	1686	96	131	1

ZAFIRA Mk I (A) (T98) MPV 11/1998-08/2005

Vehicle	Engine	Fuel	Date	CC	KW	CV	Traction
1.6 16V	X 16 XEL Z 16 XE	1	04/1999-08/2005	1598	74	101	1
1.8 16V	X 18 XE1	1	05/1999-08/2000	1796	85	116	1
1.8 16V	Z 18 XE	1	09/2000-08/2005	1796	92	125	1
2.2 16V	Z 22 SE	1	11/1998-08/2004	2198	108	147	1
1.6 CNG	Z 16 YNG	16	09/2001-06/2005	1598	71	97	1
1.6 Dualfuel	X 16 XEL	18	11/1998-08/2005	1598	74	101	1
1.8 Dualfuel	Z 18 XE	18	09/2000-08/2005	1796	92	125	1
2.0 DI 16V	X 20 DTL	2	10/1999-08/2005	1995	60	82	1
2.0 DTI 16V	Y 20 DTH	2	04/1999-08/2005	1995	74	101	1
2.2 D		2	06/2001-06/2005	2172	92	125	1

ZAFIRA Mk II (B) (A05) MPV 04/2005-11/2014

Vehicle	Engine	Fuel	Date	CC	KW	CV	Traction
1.8	A 18 XEL	1	04/2013-11/2014	1796	88	120	1
1.8	A 18 XER Z 18 XER	1	04/2005-11/2014	1796	103	140	1

Return
