Product 78BD9101-2 - Web Catalogo

Description: Brake disc
Axe: Rear
No. of Pieces: 2
Barcode: 8424073149312
Url: https://catalogonuevo.icerbrakes.com/Producto/Details?idProducto=78BD9101-2
Weight (gr.): 9196

R90 Homologation: 90R-02C0453/0098
Measures: Ø270x10x67
: Brake Disc Type: solid; Minimum thickness [mm]: 8; Hole Arrangement/Number: 5; Bolt Hole Circle Ø [mm]: 110; Wheel Hub Diameter [mm]: 65.5

Reference applications

Vehicle	Engine	Fuel	Date	CC	KW	CV	Traction
2.0	LE4(122CUL4)	1	01/1992-03/1993	1998	85	116	2
2.2 (19)	L06(134CUL4)	1	10/1994-12/1998	2198	85	116	2
2.9 GLS		1	10/1992-07/1997	2935	107	145	2

Vehicle	Engine	Fuel	Date	CC	KW	CV	Traction
1.8 (L67)	Z 18 XE	1	09/2005-10/2010	1796	92	125	1
1.8 (L67)	A 18 XER Z 18 XER	1	09/2005-10/2010	1796	103	140	1

Vehicle	Engine	Fuel	Date	CC	KW	CV	Traction
1.4 16V	Z 14 XEP	1	08/2005-	1364	66	90	1
1.6	Z 16 SE	1	10/2001-	1598	64	87	1
1.6 CNG 16V	Z 16 YNG	16	06/2006-	1598	69	94	1
1.6 CNG 16V	Z 16 YNG	16	04/2005-	1598	71	97	1
1.3 CDTI 16V	Z 13 DT	2	08/2005-	1248	51	69	1
1.3 CDTI 16V	Z 13 DTJ	2	10/2005-12/2012	1248	55	75	1
1.7 DI 16V	Y 17 DTL	2	10/2001-	1686	48	65	1
1.7 DTI 16V	Y 17 DT	2	10/2001-	1686	55	75	1

Vehicle	Engine	Fuel	Date	CC	KW	CV	Traction
1.6		1	10/2001-09/2006	1598	62	84	1
1.6	Z 16 SE	1	10/2001-09/2006	1598	64	87	1
1.6 CNG	Z 16 YNG	16	06/2006-12/2011	1598	69	94	1
1.6 CNG	Z 16 YNG	16	04/2005-01/2011	1598	71	97	1
1.7 DI 16V	Y 17 DTL	2	10/2001-06/2004	1686	48	65	1
1.7 DTI 16V	Y 17 DT	2	10/2001-06/2004	1686	55	75	1

Vehicle	Engine	Fuel	Date	CC	KW	CV	Traction
1.8 (F19, M19, N19)	E 18 NVR	1	09/1987-03/1994	1796	65	88	2
1.8 (F19, M19, N19)	18 SEH	1	09/1986-03/1994	1796	85	115	2
1.8 N (F19, M19, N19)	18 NV	1	09/1986-08/1987	1796	60	82	2
1.8 N (F19, M19, N19)	18 SV	1	11/1986-09/1988	1796	63	86	2
1.8 S (F19, M19, N19)	18 NV 18 SV	1	09/1986-03/1994	1796	66	90	2
2.0 (F19, M19, N19)	C 20 NEJ	1	09/1990-03/1994	1998	73	99	2
2.0 (F19, M19, N19)	C 20 NEF	1	09/1990-03/1994	1998	74	100	2
2.0 (F19, M19, N19)		1	09/1987-04/1994	1998	85	116	2
2.0 (F19, M19, N19)	20 SE	1	09/1986-03/1994	1998	90	122	2
2.0 i (F19, M19, N19)	C 20 NE	1	09/1986-03/1994	1998	85	115	2
2.4 i (F19, M19, N19)	C 24 NE	1	09/1988-03/1994	2410	92	125	2
2.6 i (F19, M19, N19)	C 26 NE	1	09/1990-03/1994	2594	110	150	2
3.0 (3000) (F19, M19, N19)	C 30 LE	1	03/1987-12/1987	2969	115	156	2
3.0 (3000) (F19, M19, N19)	30 NE	1	03/1987-09/1990	2969	130	177	2
3.0 (3000) Cat (F19, M19, N19)	C 30 NE	1	03/1988-03/1994	2969	130	177	2
3.0 24V (3000) (F19, M19, N19)	C 30 SEJ	1	09/1989-03/1994	2969	147	200	2
3.0 24V (3000) (F19, M19, N19)	C 30 SE	1	09/1989-03/1994	2969	150	204	2
3.0 24V Evolution500 (F19, M19, N19)	C 30 XEI	1	03/1991-07/1992	2969	169	230	2
3.6 24V Lotus (F19, M19, N19)	C 36 GET	1	08/1990-09/1992	3638	277	377	2
2.3 D (F19, M19, N19)	23 YD	2	10/1986-03/1994	2260	54	73	2
2.3 TD (F19, M19, N19)	23 YDT	2	10/1986-08/1988	2260	66	90	2
2.3 TD Interc. (F19, M19, N19)	23 DTR	2	08/1988-03/1994	2260	74	100	2

Vehicle	Engine	Fuel	Date	CC	KW	CV	Traction
1.8 (F35, M35)	E 18 NVR	1	09/1987-03/1994	1796	65	88	2
1.8 (F35, M35)	18 SEH	1	09/1986-03/1994	1796	85	115	2
1.8 N (F35, M35)	18 NV	1	09/1986-08/1987	1796	60	82	2
1.8 N (F35, M35)	18 SV	1	11/1986-09/1988	1796	63	86	2
1.8 S (F35, M35)	18 SV	1	09/1986-03/1994	1796	66	90	2
2.0 (F35, M35)	C 20 NEF	1	09/1990-03/1994	1998	74	100	2
2.0 (F35, M35)	C 20 NE	1	09/1987-04/1994	1998	85	116	2
2.0 (F35, M35)	20 SE	1	09/1986-03/1994	1998	90	122	2
2.0 i (F35, M35)	C 20 NEJ	1	09/1990-03/1994	1998	73	99	2
2.0 i (F35, M35)	C 20 NE	1	09/1986-04/1994	1998	85	115	2
2.4 i (F35, M35)	C 24 NE	1	09/1988-03/1994	2410	92	125	2
2.6		1	09/1987-04/1994	2580	135	184	1
2.6 i (F35, M35)	C 26 NE	1	09/1990-03/1994	2594	110	150	2
3.0 (F35, M35)	C 30 LE	1	03/1987-03/1994	2969	115	156	2
3.0 (F35, M35)	30 NE	1	03/1987-09/1990	2969	130	177	2
3.0 24V (F35, M35)	C 30 SEJ	1	09/1989-03/1994	2969	147	200	2
3.0 24V Omega 3000 (F35, M35)	C 30 SE	1	09/1988-04/1994	2969	150	204	2
3.0 Cat (F35, M35)	C 30 NE	1	03/1987-03/1994	2969	130	177	2
2.3 D (F35, M35)	23 YD	2	09/1986-03/1994	2260	54	73	2
2.3 TD (F35, M35)	23 YDT	2	09/1986-08/1988	2260	66	90	2
2.3 TD Interc. (F35, M35)	23 DTR	2	09/1988-03/1994	2260	74	100	2

Vehicle	Engine	Fuel	Date	CC	KW	CV	Traction
2.8	28 H	1	02/1978-04/1981	2784	103	140	2
3.0	30 H	1	04/1978-07/1982	2969	110	150	2
3.0	C 30 LE	1	09/1985-08/1987	2969	115	156	2
3.0 E	30 E	1	02/1978-12/1986	2969	132	180	2

Vehicle	Engine	Fuel	Date	CC	KW	CV	Traction
2.5 i (P19)	25 NE	1	09/1990-09/1993	2490	103	140	2
2.6 i (P19)	C 26 NE	1	09/1990-09/1993	2594	110	150	2
3.0 (P19)	C 30 LE	1	09/1987-09/1993	2969	115	156	2
3.0 (P19)	30 NE	1	01/1988-09/1990	2969	130	177	2
3.0 24V (P19)	C 30 SE	1	09/1989-09/1993	2969	150	204	2
3.0 i Cat (P19)	C 30 NE	1	01/1988-09/1993	2969	130	177	2
3.6 (P19)	C 36 NEI	1	09/1991-08/1993	3615	147	200	2

Vehicle	Engine	Fuel	Date	CC	KW	CV	Traction
1.8	E 18 NVR	1	09/1987-03/1994	1796	65	88	2
1.8 i	18 SEH	1	09/1986-03/1994	1796	85	115	2
1.8 N		1	09/1986-08/1987	1796	60	82	2
1.8 S	18 SV	1	09/1986-03/1994	1796	66	90	2
2.0		1	09/1990-03/1994	1998	73	99	2
2.0	C 20 NEF	1	09/1990-03/1994	1998	74	100	2
2.0	C 20 NE	1	09/1986-03/1994	1998	85	115	2
2.0 i	20 SE	1	09/1986-03/1994	1998	90	122	2
2.4 i		1	09/1988-03/1994	2410	92	125	2
2.6 i	C 26 NE	1	09/1990-03/1994	2594	110	150	2
3.0 3000	30 NE	1	03/1987-09/1990	2969	130	177	2
3.0 3000 24V	C 30 SE	1	09/1989-03/1994	2969	150	204	2
3.6 24V Lotus	C 36 GET	1	08/1990-09/1992	3638	277	377	2
3000		1	03/1987-12/1987	2969	115	156	2
3000 24V	C 30 SEJ	1	09/1989-03/1994	2969	147	200	2
3000 Cat	C 30 NE	1	03/1988-03/1994	2969	130	177	2
2.2 TD	23 YDT	2	10/1986-08/1988	2260	66	90	2
2.3 D	23 YD	2	09/1986-03/1994	2260	54	73	2
2.3 TD Interc.	23 DTR	2	08/1988-03/1994	2260	74	100	2

Vehicle	Engine	Fuel	Date	CC	KW	CV	Traction
1.8	E 18 NVR	1	09/1987-03/1994	1796	65	88	2
1.8 i	18 SEH	1	09/1986-03/1994	1796	85	115	2
1.8 N		1	09/1986-08/1987	1796	60	82	2
1.8 S	18 SV	1	09/1986-03/1994	1796	66	90	2
2.0		1	09/1990-03/1994	1998	74	100	2
2.0	C 20 NE	1	09/1986-03/1994	1998	85	115	2
2.0 i		1	09/1990-03/1994	1998	73	99	2
2.0 i	20 SE	1	09/1986-03/1994	1998	90	122	2
2.4 i		1	09/1988-03/1994	2410	92	125	2
2.6 i	C 26 NE	1	09/1990-03/1994	2594	110	150	2
3.0	C 30 NE	1	03/1987-03/1994	2969	130	177	2
3.0 24V	C 30 SEJ	1	09/1989-03/1994	2969	147	200	2
2.2 TD	23 YDT	2	09/1986-08/1988	2260	66	90	2
2.3 D	23 YD	2	09/1986-03/1994	2260	54	73	2
2.3 TD Interc.	23 DTR	2	09/1988-03/1994	2260	74	100	2

Vehicle	Engine	Fuel	Date	CC	KW	CV	Traction
2.8	28 H	1	02/1978-04/1981	2784	103	140	2
2.9		1	04/1978-07/1982	2969	110	150	2
2.9		1	09/1985-08/1987	2969	115	156	2
2.9 E	30 E	1	02/1978-12/1986	2969	132	180	2
3.0	30 E	1	10/1979-10/1982	2969	132	180	2

Vehicle	Engine	Fuel	Date	CC	KW	CV	Traction
2.8	28 H	1	10/1979-10/1982	2784	103	140	2
2.9	30 E	1	02/1978-08/1986	2969	132	180	2
3.0	30 E	1	10/1979-10/1982	2969	132	180	2

Vehicle	Engine	Fuel	Date	CC	KW	CV	Traction
2.5 i	25 E	1	09/1984-08/1987	2490	103	140	2
3.0 i	30 E	1	09/1984-12/1986	2968	132	180	2

Vehicle	Engine	Fuel	Date	CC	KW	CV	Traction
2.5 i	25 E	1	09/1987-10/1990	2490	103	140	2
2.6 i	C 26 NE	1	09/1990-09/1993	2594	110	150	2
3.0		1	09/1987-09/1993	2969	115	156	2
3.0	30 NE C 30 NE	1	01/1988-09/1990	2969	130	177	2
3.0	30 NE	1	09/1987-08/1988	2969	135	183	2
3.0 24V	C 30 SE	1	09/1989-09/1993	2969	150	204	2
3.0 i Cat	30 NE C 30 NE	1	01/1988-09/1993	2969	130	177	2
