Product 78BD9108-2 - Web Catalogo

Description: Brake disc
Axe: Rear
No. of Pieces: 2
Barcode: 8424073149343
Url: https://catalogonuevo.icerbrakes.com/Producto/Details?idProducto=78BD9108-2
Weight (gr.): 6280

R90 Homologation: 90R-02C0415/0035
Measures: Ø240x10x42
: Brake Disc Type: solid; Minimum thickness [mm]: 8; Hole Arrangement/Number: 4; Bolt Hole Circle Ø [mm]: 100; Wheel Hub Diameter [mm]: 57

Reference applications

Brand	OE Reference
OPEL	5 069 111
OPEL	5 69 108
OPEL	5 69 111
VAUXHALL	90 498 304
VAUXHALL	91 177 71
VAUXHALL	91 965 87

Maker	Cross reference
ATE	24.0110-0251.1
BOSCH	0 986 478 882
BREMBO	08.7626.10
BREMBO	08.7626.75
LETEC	LBG027S
NECTO	WN970
ROAD HOUSE	6570.00
SANLI	SL10009
TRW	DF4050

CHEVROLET

ASTRA () Estate 09/1994-12/2011

Vehicle	Engine	Fuel	Date	CC	KW	CV	Traction
1.8 GLS		1	08/2002-12/2011	1796	81	110	1
2.0	X 20 XEV	1	10/1999-07/2002	1998	94	128	1
2.0	C 20 SEL	1	08/2002-07/2005	1998	100	136	1
2.2		1	01/2001-12/2003	2198	108	147	1

ASTRA () Hatchback 09/1998-12/2011

Vehicle	Engine	Fuel	Date	CC	KW	CV	Traction
1.8 (08, 48)	C 18 NE C 18 YE LC5(110CUL4)	1	09/1998-12/2011	1796	81	110	1
2.0	LE4(122CUL4)	1	08/2002-12/2011	1998	85	116	1
2.0	X 20 XEV	1	03/1999-07/2002	1998	94	128	1
2.0 (08, 48)	L34(122CUL4)	1	08/2002-07/2005	1998	100	136	1
2.2	Z 22 SE	1	08/2000-08/2004	2198	108	147	1
1.7 Di	Y 17 DT	2	08/2000-08/2003	1686	55	75	1
2.0 DTI	LD1	2	08/2002-12/2011	1995	74	101	1

ASTRA () Saloon 10/1998-12/2011

Vehicle	Engine	Fuel	Date	CC	KW	CV	Traction
1.8	2H9	1	08/2002-06/2005	1796	92	125	1
1.8 Flexfuel	C 18 NE C 18 YE	1	03/1999-12/2011	1796	81	110	1
2.0 GL	LE4(122CUL4)	1	08/2002-12/2011	1998	85	116	1
2.0 GLS	X 20 XEV	1	03/1999-07/2002	1998	94	128	1
2.0 GLS (69)	C 20 SEL L34(122CUL4)	1	08/2002-12/2011	1998	100	136	1
2.0 DTi GLS	LD1	2	08/2002-12/2011	1995	74	101	1

CORSA () Saloon 03/1994-12/2010

Vehicle	Engine	Fuel	Date	CC	KW	CV	Traction
1.6 GLS (19)	B 16 NE L01(98CUL4)	1	08/1994-07/2002	1598	68	92	1
1.6 GS	L91	1	08/1997-07/2002	1598	75	102	1
1.7 D	2H7	2	08/2000-07/2002	1686	44	60	1

CORSA () Hatchback 03/1994-12/2010

Vehicle	Engine	Fuel	Date	CC	KW	CV	Traction
1.6 GLS (08, 68)	C 16 NE L01(98CUL4)	1	08/1994-07/2002	1598	68	92	1

CORSA () Pickup 08/1994-12/2010

Vehicle	Engine	Fuel	Date	CC	KW	CV	Traction
1.6 (80)	C 16 NE L01(98CUL4)	1	08/1994-07/2002	1598	68	92	1

OPEL

ASTRA G (T98) Hatchback 02/1998-12/2009

Vehicle	Engine	Fuel	Date	CC	KW	CV	Traction
1.2 16V (F08, F48)	X 12 XE	1	02/1998-09/2000	1199	48	65	1
1.2 16V (F08, F48)	Z 12 XE	1	09/2000-01/2005	1199	55	75	1
1.4 (F08, F48)	Z 14 XEP	1	09/2007-12/2009	1364	66	90	1
1.4 16V (F08, F48)	X 14 XE Z 14 XE	1	02/1998-01/2005	1389	66	90	1
1.6		1	06/2002-03/2004	1598	70	95	1
1.6 (F08, F48)	X 16 SZR	1	02/1998-09/2000	1598	55	75	1
1.6 (F08, F48)	Z 16 SE	1	09/2000-01/2005	1598	62	84	1
1.8 16V (F08, F48)	X 18 XE1	1	02/1998-09/2000	1796	85	116	1
1.8 16V (F08, F48)	Z 18 XE	1	09/2000-01/2005	1796	92	125	1
1.4 LPG (F08, F48)	X 14 XE Z 14 XE	18	02/1998-01/2005	1389	66	90	1
1.6 LPG (F08, F48)		18	03/1998-01/2005	1598	55	75	1
1.6 LPG (F08, F48)	X 16 XEL Z 16 XE	18	03/1998-01/2005	1598	74	101	1
1.6 LPG (F08, F48)	Z 16 XEP	18	11/2002-06/2007	1598	76	103	1
1.6 LPG (F48)		18	03/1998-01/2005	1598	62	84	1
1.7 CDTI (F08, F48)	Z 17 DTL	2	04/2003-01/2005	1686	59	80	1
1.7 DTI 16V (F08, F48)	Y 17 DT	2	02/2000-01/2005	1686	55	75	1
1.7 TD (F08, F48)	X 17 DTL	2	02/1998-08/2000	1699	50	68	1
2.0 DI (F08, F48)	X 20 DTL Y 20 DTL	2	02/1998-01/2005	1995	60	82	1
2.0 DTI 16V (F08, F48)	Y 20 DTH	2	08/1999-01/2005	1995	74	101	1

ASTRA G (T98) Estate 02/1998-07/2005

Vehicle	Engine	Fuel	Date	CC	KW	CV	Traction
1.2 16V (F35)	X 12 XE	1	02/1998-09/2000	1199	48	65	1
1.2 16V (F35)	Z 12 XE	1	09/2000-07/2004	1199	55	75	1
1.4 16V (F35)	X 14 XE Z 14 XE	1	06/1998-07/2004	1389	66	90	1
1.6 (F35)	X 16 SZR	1	02/1998-09/2000	1598	55	75	1
1.6 16V (F35)	X 16 XEL Z 16 XE	1	02/1998-07/2004	1598	74	101	1
1.8 16V (F35)	X 18 XE1	1	02/1998-09/2000	1796	85	116	1
1.4 LPG (F35)	X 14 XE Z 14 XE	18	03/1998-07/2004	1389	66	90	1
1.6 LPG (F35)		18	03/1998-09/2000	1598	55	75	1
1.6 LPG (F35)		18	09/2000-07/2004	1598	62	84	1
1.6 LPG (F35)	X 16 XEL Z 16 XE	18	03/1998-07/2004	1598	74	101	1
1.6 LPG (F35)	Z 16 XEP	18	06/2002-07/2004	1598	76	103	1
1.7 CDTI (F35)	Z 17 DTL	2	04/2003-05/2004	1686	59	80	1
1.7 DTI 16V (F35)	Y 17 DT	2	02/2000-07/2004	1686	55	75	1
1.7 TD (F35)	X 17 DTL	2	02/1998-08/2000	1699	50	68	1
2.0 DI (F35)	X 20 DTL Y 20 DTL	2	02/1998-07/2004	1995	60	82	1
2.0 DTI 16V (F35)	Y 20 DTH	2	08/1999-07/2004	1995	74	101	1

ASTRA G (T98) Saloon 03/1998-12/2009

Vehicle	Engine	Fuel	Date	CC	KW	CV	Traction
1.2 16V (F69)	X 12 XE	1	09/1998-09/2000	1199	48	65	1
1.2 16V (F69)	Z 12 XE	1	09/2000-01/2005	1199	55	75	1
1.4 (F69)	Z 14 XEP	1	09/2007-12/2009	1364	66	90	1
1.4 16V (F69)	X 14 XE Z 14 XE	1	09/1998-01/2005	1389	66	90	1
1.6 (F69)	X 16 SZR	1	09/1998-09/2000	1598	55	75	1
1.6 (F69)	Z 16 SE	1	09/2000-01/2005	1598	62	84	1
1.6 16V (F69)	X 16 XEL Z 16 XE	1	09/1998-01/2005	1598	74	101	1
1.8		1	02/2003-01/2005	1796	81	110	1
1.8 16V (F69)	X 18 XE1	1	09/1998-09/2000	1796	85	116	1
1.8 16V (F69)	Z 18 XE	1	06/2000-01/2005	1796	92	125	1
1.4 LPG (F69)	X 14 XE Z 14 XE	18	03/1998-01/2005	1389	66	90	1
1.6 LPG (F69)		18	10/1998-06/2000	1598	55	75	1
1.6 LPG (F69)		18	09/2000-01/2005	1598	62	84	1
1.6 LPG (F69)	X 16 XEL Z 16 XE	18	06/2002-01/2005	1598	74	101	1
1.7 CDTI (F69)	Z 17 DTL	2	04/2003-12/2009	1686	59	80	1
1.7 DTI 16V (F69)	Y 17 DT	2	02/2000-01/2005	1686	55	75	1
1.7 TD (F69)	X 17 DTL	2	09/1998-08/2000	1699	50	68	1
2.0 DI (F69)	X 20 DTL Y 20 DTL	2	09/1998-01/2005	1995	60	82	1
2.0 DTI 16V (F69)	Y 20 DTH	2	08/1999-01/2005	1995	74	101	1

ASTRA G (F70) Estate Van 09/1998-04/2005

Vehicle	Engine	Fuel	Date	CC	KW	CV	Traction
1.2 (F70)	X 12 XE	1	09/1998-08/2000	1199	48	65	1
1.4 (F70)	X 14 XE Z 14 XE	1	09/1998-04/2005	1389	66	90	1
1.6 (F70)	X 16 SZR	1	01/1999-09/2000	1598	55	75	1
1.6 (F70)	Z 16 SE	1	09/2000-04/2005	1598	62	84	1
1.6 (F70)	C 16 SEL Z 16 XE	1	09/1998-01/2004	1598	74	101	1
1.6 (F70)	Z 16 XEP	1	02/2004-11/2004	1598	76	103	1
1.6 LPG (F70)		18	01/1999-09/2000	1598	55	75	1
1.6 LPG (F70)		18	12/2000-04/2005	1598	62	84	1
1.7 CDTi (F70)	Z 17 DTL	2	07/2003-11/2004	1686	59	80	1
1.7 DTI 16V (F70)	Y 17 DT	2	02/2000-04/2005	1686	55	75	1
1.7 TD (F70)	X 17 DTL	2	01/1999-04/2005	1699	50	68	1
2.0 DI (F70)	X 20 DTL Y 20 DTL	2	01/1999-04/2005	1995	60	82	1

ASTRA G (T98) Convertible 03/2001-10/2005

Vehicle	Engine	Fuel	Date	CC	KW	CV	Traction
1.6 16V (F67)	Z 16 XE	1	03/2001-10/2005	1598	74	101	1

ASTRA G CLASSIC (T98) Saloon 03/2004-07/2009

Vehicle	Engine	Fuel	Date	CC	KW	CV	Traction
1.4 16V (F69)	Z 14 XE	1	05/2004-07/2009	1389	66	90	1
1.6 16V (F69)	Z 16 XE	1	03/2004-01/2008	1598	74	101	1

ASTRA G CLASSIC (T98) Hatchback 03/2004-07/2009

Vehicle	Engine	Fuel	Date	CC	KW	CV	Traction
1.4 16V (F08, F48)	Z 14 XE	1	05/2004-07/2009	1389	66	90	1
1.6 (F08, F48)	Z 16 XEP	1	03/2006-06/2008	1598	76	103	1
1.6 16V (F08, F48)	Z 16 XE	1	05/2004-02/2006	1598	74	101	1
1.7 CDTI (F08, F48)	Z 17 DTL	2	06/2004-07/2009	1686	59	80	1

ASTRA G CLASSIC Caravan (F35) Estate 03/2004-07/2009

Vehicle	Engine	Fuel	Date	CC	KW	CV	Traction
1.4 (F35)	Z 14 XEP	1	10/2007-07/2009	1364	66	90	1
1.4 16V	Z 14 XE	1	07/2004-09/2007	1389	66	90	1
1.6	Z 16 XE	1	06/2004-02/2006	1598	74	101	1
1.6	Z 16 XEP	1	02/2006-07/2009	1598	76	103	1
1.7 CDTi	Z 17 DTL	2	05/2004-07/2009	1686	59	80	1

ASTRA H (A04) Hatchback 01/2004-05/2014

Vehicle	Engine	Fuel	Date	CC	KW	CV	Traction
1.2		1	10/2006-	1199	48	65	1
1.2 (L48)	Z 12 XEP	1	08/2005-10/2010	1229	59	80	1
1.4		1	04/2004-10/2004	1364	59	80	1
1.4 (L48)	Z 14 XEL	1	04/2004-10/2004	1364	55	75	1
1.4 (L48)	Z 14 XEP	1	03/2004-10/2010	1364	66	90	1
1.6 (L48)	Z 16 XE1 Z 16 XEP	1	03/2004-10/2010	1598	77	105	1
1.6 (L48)	A 16 XER Z 16 XER	1	12/2006-05/2014	1598	85	116	1
1.6 CNG		1	11/2005-	1598	69	94	1
1.4 LPG (L48)	Z 14 XEP	18	08/2009-10/2010	1364	66	90	1

ASTRA H (L70) Estate Van 02/2004-10/2014

Vehicle	Engine	Fuel	Date	CC	KW	CV	Traction
1.4 EcoTec (L70)	Z 14 XEP	1	12/2004-12/2012	1364	66	90	1
1.6 EcoTec (L70)	Z 16 XEP	1	02/2004-11/2004	1598	76	103	1
1.6 EcoTec (L70)	Z 16 XER	1	10/2006-12/2010	1598	85	116	1
1.3 CDTI (L70)	Z 13 DTH	2	08/2005-10/2010	1248	66	90	1
1.7 CDTI (L70)	Z 17 DTL	2	12/2004-07/2007	1686	59	80	1
1.7 CDTI (L70)	Z 17 DTH	2	03/2004-10/2010	1686	74	101	1
1.7 CDTI (L70)	A 17 DTJ Z 17 DTJ	2	02/2007-10/2014	1686	81	110	1
1.7 CDTI (L70)	A 17 DTR Z 17 DTR	2	02/2007-10/2010	1686	92	125	1
1.9 CDTI (L70)	Z 19 DTL	2	08/2005-12/2012	1910	74	101	1
1.9 CDTI (L70)	Z 19 DT	2	09/2005-10/2010	1910	88	120	1
1.9 CDTI (L70)	Z 19 DTH	2	09/2004-10/2010	1910	110	150	1
1.9 CDTI 16V (L70)	Z 19 DTJ	2	08/2004-10/2010	1910	88	120	1

ASTRA H (A04) Estate 08/2004-05/2014

Vehicle	Engine	Fuel	Date	CC	KW	CV	Traction
1.4 (L35)	Z 14 XEL	1	08/2004-10/2010	1364	55	75	1
1.4 (L35)	Z 14 XEP	1	08/2004-10/2010	1364	66	90	1
1.6 (L35)	Z 16 XE1 Z 16 XEP	1	08/2004-10/2010	1598	77	105	1
1.6 CNG		1	11/2005-	1598	69	94	1
1.4 LPG (L35)	Z 14 XEP	18	08/2009-10/2010	1364	66	90	1
1.6 LPG (L35)	Z 16 XER	18	08/2009-10/2010	1598	85	116	1

ASTRA H GTC (A04) Hatchback 03/2005-10/2010

Vehicle	Engine	Fuel	Date	CC	KW	CV	Traction
1.2		1	10/2006-	1199	48	65	1
1.2 (L08)		1	08/2005-10/2010	1229	59	80	1
1.4 (L08)	Z 14 XEL	1	03/2005-10/2010	1364	55	75	1
1.4 (L08)	Z 14 XEP	1	03/2005-10/2010	1364	66	90	1
1.6 (L08)	Z 16 XE1 Z 16 XEP	1	03/2005-10/2010	1598	77	105	1
1.6 (L08)	Z 16 XER	1	12/2006-10/2010	1598	85	116	1
1.6 CNG		1	11/2005-	1598	69	94	1
1.6 Turbo (L08)	A 16 LET Z 16 LET	1	02/2007-10/2010	1598	132	180	1
1.7 CDTi (L08)	Z 17 DTL	2	03/2005-10/2010	1686	59	80	1

ASTRA H TwinTop (A04) Convertible 09/2005-10/2010

Vehicle	Engine	Fuel	Date	CC	KW	CV	Traction
1.6 (L67)	Z 16 XE1 Z 16 XEP	1	09/2005-10/2010	1598	77	105	1
1.6 (L67)	Z 16 XER	1	12/2006-10/2010	1598	85	116	1

ASTRA H CLASSIC (A04) Estate 12/2006-

Vehicle	Engine	Fuel	Date	CC	KW	CV	Traction
1.4 (L35)	Z 14 XEP	1	01/2009-	1364	66	90	1
1.6 (L35)	Z 16 XER	1	12/2006-05/2014	1598	85	116	1
1.8 (L35)	Z 18 XER	1	01/2012-05/2014	1796	103	140	1
1.7 CDTI (L35)	Z 17 DTJ	2	01/2009-	1686	81	110	1

ASTRA H (A04) Saloon 02/2007-05/2014

Vehicle	Engine	Fuel	Date	CC	KW	CV	Traction
1.4 (L69)	Z 14 XEP	1	02/2007-06/2010	1364	66	90	1
1.6 (L69)	Z 16 XEP	1	02/2007-06/2010	1598	77	105	1
1.8 (L69)	A 18 XER Z 18 XER	1	02/2007-09/2012	1796	103	140	1
1.3 CDTi (L69)	Z 13 DTH	2	02/2007-10/2010	1248	66	90	1
1.7 CDTi (L69)	Z 17 DTJ	2	02/2007-05/2014	1686	81	110	1

ASTRA H CLASSIC (A04) Saloon 02/2007-

Vehicle	Engine	Fuel	Date	CC	KW	CV	Traction
1.6 (L69)	Z 16 XER	1	01/2009-05/2014	1598	85	116	1
1.8 (L69)	Z 18 XER	1	02/2007-09/2012	1796	103	140	1
1.7 CDTi (L69)	Z 17 DTJ	2	01/2009-	1686	81	110	1
1.7 CDTi (L69)	A 17 DTR Z 17 DTR	2	01/2009-	1686	92	125	1

ASTRA H CLASSIC (A04) Hatchback 01/2009-

Vehicle	Engine	Fuel	Date	CC	KW	CV	Traction
1.4 (L48)	Z 14 XEP	1	01/2009-	1364	66	90	1
1.6 (L48)	Z 16 XER	1	01/2009-	1598	85	116	1
1.7 CDTI (L48)	A 17 DTJ Z 17 DTJ	2	01/2009-	1686	81	110	1

MERIVA A (X03) MPV 05/2003-05/2010

Vehicle	Engine	Fuel	Date	CC	KW	CV	Traction
1.4 16V Twinport (E75)	Z 14 XEP	1	07/2004-05/2010	1364	66	90	1
1.6 (E75)	Z 16 SE	1	05/2003-05/2010	1598	64	87	1
1.4 16V Twinport LPG (E75)	Z 14 XEP	18	07/2004-05/2010	1364	66	90	1

VAUXHALL

ASTRAVAN Mk IV (G) (T98) Estate Van 01/1993-08/2006

Vehicle	Engine	Fuel	Date	CC	KW	CV	Traction
1.4 16V	Z 14 XE	1	09/2000-05/2005	1389	66	90	1
1.6 i	X 16 SZR	1	08/1998-09/2000	1598	55	75	1
1.6 i	Z 16 SE	1	09/2000-08/2006	1598	62	84	1
1.6 Dualfuel	X 16 SZR	18	02/1998-12/2000	1598	55	75	1
1.6 Dualfuel	Z 16 XE	18	07/2000-08/2005	1598	74	101	1
1.6 Dualfuel 16V	Z 16 XEP	18	10/2004-12/2005	1598	77	105	1
1.7 DTI 16V	Y 17 DT	2	04/2001-08/2006	1686	55	75	1
1.7 TD	X 17 DTL	2	08/1998-08/2006	1700	50	68	1

ASTRA Mk IV (G) (T98) Hatchback 02/1998-05/2005

Vehicle	Engine	Fuel	Date	CC	KW	CV	Traction
1.2 16V (F08, F48)		1	02/1998-09/2000	1199	48	65	1
1.2 16V (F08, F48)		1	09/2000-05/2005	1199	55	75	1
1.4 16V (F08, F48)	X 14 XE Z 14 XE	1	02/1998-05/2005	1389	66	90	1
1.6 (F08, F48)	X 16 SZR	1	02/1998-09/2000	1598	55	75	1
1.6 (F08, F48)	Z 16 SE	1	09/2000-05/2005	1598	62	84	1
1.6 (F08, F48)	Z 16 XEP	1	12/2002-05/2005	1598	76	103	1
1.6 16V (F08, F48)	X 16 XEL Z 16 XE	1	02/1998-05/2005	1598	74	101	1
1.8 16V (F08, F48)	X 18 XE1	1	02/1998-09/2000	1796	85	116	1
1.8 16V (F08, F48)	Z 18 XE	1	09/2000-05/2005	1796	92	125	1
1.4 16V Dualfuel (F08, F48)	X 14 XE Z 14 XE	18	09/1999-06/2003	1389	66	90	1
1.6 Dualfuel (F08, F48)	X 16 SZR	18	02/1998-12/2000	1598	55	75	1
1.6 Dualfuel (F08, F48)	Z 16 SE	18	09/2002-05/2005	1598	63	85	1
1.6 Dualfuel (F08, F48)	X 16 XEL Z 16 XE	18	09/1999-08/2004	1598	74	101	1
1.6 Dualfuel (F08)	Z 16 SE	18	07/2000-05/2005	1598	62	86	1
1.8 16V Dualfuel (F08, F48)	Z 18 XE	18	09/2002-05/2005	1796	87	118	1
2.0 DI (F48)	X 20 DTL Y 20 DTL	2	02/1998-05/2005	1995	60	82	1
2.0 DTI 16V (F48)	Y 20 DTH	2	08/1999-05/2005	1995	74	101	1

ASTRA Mk IV (G) (T98) Saloon 02/1998-05/2005

Vehicle	Engine	Fuel	Date	CC	KW	CV	Traction
1.2 16V		1	09/1998-09/2000	1199	48	65	1
1.2 16V		1	09/2000-05/2005	1199	55	75	1
1.4 16V	X 14 XE Z 14 XE	1	09/1998-05/2005	1389	66	90	1
1.6	X 16 SZR	1	09/1998-09/2000	1598	55	75	1
1.6	Z 16 SE	1	09/2000-05/2005	1598	62	84	1
1.6 16V	X 16 XEL Z 16 XE	1	09/1998-05/2005	1598	74	101	1
1.8 16V	X 18 XE1	1	02/1998-07/2004	1796	85	116	1
1.8 16V	Z 18 XE	1	02/1998-07/2004	1796	92	125	1
1.6 Dualfuel		18	02/1998-12/2000	1598	55	75	1
1.6 Dualfuel	Z 16 SE	18	07/2000-05/2005	1598	62	86	1
1.6 Dualfuel	Z 16 SE	18	09/2002-05/2005	1598	63	85	1
1.6 Dualfuel	X 16 XEL Z 16 XE	18	09/1999-08/2004	1598	74	101	1
1.8 16V Dualfuel	Z 18 XE	18	02/1998-07/2004	1796	87	118	1
2.0 DI	X 20 DTL Y 20 DTL	2	02/1998-07/2004	1995	60	82	1
2.0 DTI 16V	Y 20 DTH	2	02/1998-07/2004	1995	74	101	1

ASTRA Mk IV (G) (T98) Estate 02/1998-05/2005

Vehicle	Engine	Fuel	Date	CC	KW	CV	Traction
1.2 16V		1	02/1998-09/2000	1199	48	65	1
1.2 16V		1	09/2000-05/2005	1199	55	75	1
1.4 16V	X 14 XE Z 14 XE	1	02/1998-05/2005	1389	66	90	1
1.6	X 16 SZR	1	03/1998-04/2004	1598	55	75	1
1.6	Z 16 XEP	1	12/2002-05/2005	1598	76	103	1
1.6 16V	X 16 XEL Z 16 XE	1	03/1998-04/2004	1598	74	101	1
1.8 16V	X 18 XE1	1	02/1998-08/2000	1796	85	116	1
1.8 16V	Z 18 XE	1	09/2000-05/2005	1796	92	125	1
1.4 16V Dualfuel	X 14 XE Z 14 XE	18	09/1999-06/2003	1389	66	90	1
1.6 Dualfuel	X 16 SZR	18	02/1998-12/2000	1598	55	75	1
1.6 Dualfuel	Z 16 SE	18	07/2000-05/2005	1598	62	86	1
1.6 Dualfuel	X 16 XEL Z 16 XE	18	09/1999-08/2004	1598	74	101	1
1.8 16V Dualfuel	Z 18 XE	18	09/2002-05/2005	1796	87	118	1
1.7 CDTI 16V	Z 17 DTL	2	04/2003-05/2005	1686	59	80	1
1.7 DTI 16V	Y 17 DT	2	02/2000-05/2005	1686	55	75	1
1.7 TD	X 17 DTL	2	02/1998-08/2000	1700	50	68	1
2.0 DI	X 20 DTL Y 20 DTL	2	03/1998-04/2004	1995	60	82	1
2.0 DTI 16V	Y 20 DTH	2	03/1998-04/2004	1995	74	101	1

ASTRA Mk IV (G) (T98) Convertible 03/2001-10/2005

Vehicle	Engine	Fuel	Date	CC	KW	CV	Traction
1.6 16V	Z 16 XEP	1	03/2003-10/2005	1598	76	103	1

ASTRA Mk V (H) (A04) Hatchback 01/2004-03/2011

Vehicle	Engine	Fuel	Date	CC	KW	CV	Traction
1.4 (L48)	Z 14 XEP	1	01/2004-05/2009	1364	66	90	1
1.6 (L48)	Z 16 XE1 Z 16 XEP	1	01/2004-05/2009	1598	77	105	1
1.6 (L48)	A 16 XER Z 16 XER	1	01/2004-05/2009	1598	85	115	1
1.6 Turbo (L48)	A 16 LET Z 16 LET	1	09/2006-09/2009	1598	132	180	1

ASTRA Mk V (H) (A04) Estate 08/2004-10/2012

Vehicle	Engine	Fuel	Date	CC	KW	CV	Traction
1.4 (L35)	Z 14 XEP	1	08/2004-03/2009	1364	66	90	1
1.6 (L35)	Z 16 XE1 Z 16 XEP	1	08/2004-03/2009	1598	77	105	1
1.6 (L35)	Z 16 XER	1	08/2004-03/2011	1598	85	115	1
1.7 CDTI (L35)	Z 17 DTL	2	08/2004-05/2009	1686	59	80	1
1.9 CDTI 16V (L35)	Z 19 DTJ	2	08/2004-03/2009	1910	88	120	1

ASTRA Mk V (H) Sport Hatch (A04) Hatchback 02/2005-11/2010

Vehicle	Engine	Fuel	Date	CC	KW	CV	Traction
1.4 i 16V (L08)	Z 14 XEP	1	03/2005-11/2010	1364	66	90	1
1.6 (L08)	Z 16 XEP	1	02/2005-11/2010	1598	77	105	1
1.6 (L08)	A 16 LET Z 16 LET	1	10/2006-11/2010	1598	132	179	1
1.6 i 16V (L08)	A 16 XER Z 16 XER	1	12/2006-11/2010	1598	85	116	1
1.7 CDTi (L08)	A 17 DTJ Z 17 DTJ	2	02/2007-11/2009	1686	81	110	1

ASTRAVAN Mk V (H) (A04) Estate Van 03/2005-

Vehicle	Engine	Fuel	Date	CC	KW	CV	Traction
1.4 i	Z 14 XEP	1	03/2005-	1364	66	90	1
1.6	Z 16 XE1 Z 16 XEP	1	03/2005-	1598	76	103	1
1.3 CDTi	Z 13 DTH	2	08/2005-	1248	66	90	1
1.7 CDTi	Z 17 DTL	2	03/2005-07/2006	1686	59	80	1
1.7 CDTi	A 17 DTJ Z 17 DTJ	2	06/2011-12/2013	1686	81	110	1
1.9 CDTI	Z 19 DT	2	03/2005-11/2011	1910	88	120	1
1.9 CDTI	Z 19 DTH	2	03/2005-11/2011	1910	110	150	1

COMBO Mk II (C) (F25) Box Body/MPV 09/2001-02/2012

Vehicle	Engine	Fuel	Date	CC	KW	CV	Traction
1.4 16V	Z 14 XE	1	10/2001-05/2007	1389	66	90	1
1.6	Z 16 SE	1	09/2001-10/2004	1598	62	84	1
1.6 CNG 16V	Y 16 YNG Z 16 YNG	16	06/2006-02/2012	1598	69	94	1
1.6 CNG 16V	Z 16 YNG	16	04/2005-02/2012	1598	71	97	1
1.3 CDTI 16V	Y 13 DT Z 13 DT	2	09/2004-02/2012	1248	51	69	1
1.3 CDTI 16V	Z 13 DTJ	2	10/2005-11/2011	1248	55	75	1

COMBO TOUR Mk II (C) (F25) MPV 09/2001-02/2012

Vehicle	Engine	Fuel	Date	CC	KW	CV	Traction
1.4	Z 14 XEP	1	10/2004-09/2010	1364	66	90	1
1.6	Z 16 SE	1	10/2001-06/2004	1598	64	87	1
1.6 CNG	Z 16 YNG	16	06/2006-09/2010	1598	69	94	1
1.6 CNG	Z 16 YNG	16	04/2005-02/2012	1598	71	97	1
1.3 CDTI 16V	Z 13 DT	2	09/2004-09/2006	1248	51	69	1
1.3 CDTI 16V	Z 13 DTJ	2	07/2006-02/2012	1248	55	75	1
1.7 DI 16V	Y 17 DTL	2	09/2001-06/2004	1686	48	65	1
1.7 DTI 16V	Y 17 DT	2	10/2001-02/2012	1686	55	75	1

MERIVA Mk I (A) (X03) MPV 01/2003-06/2010

Vehicle	Engine	Fuel	Date	CC	KW	CV	Traction
1.4 16V Twinport	Z 14 XEP	1	01/2003-06/2010	1364	66	90	1
1.6 i	Z 16 SE	1	01/2003-06/2010	1598	64	87	1

Return
