Product 78BD9116-2
- Description
- Brake disc
- Axe
- Rear
- No. of Pieces
- 2
- Barcode
-
8424073149381
- Url
- https://catalogonuevo.icerbrakes.com/Producto/Details?idProducto=78BD9116-2
- Weight (gr.)
- 7636
- R90 Homologation
-
90R-02C0415/0009
- Measures
- Ø264x10x42
-
Brake Disc Type:
solid -
Minimum thickness [mm]:
8 -
Hole Arrangement/Number:
4 -
Bolt Hole Circle Ø [mm]:
100 -
Wheel Hub Diameter [mm]:
57
| Brand | OE Reference |
|---|---|
| OPEL | 5 69 116 |
| VAUXHALL | 93 176 548 |
| Maker | Cross reference |
|---|---|
| ATE | 24.0110-0291.1 |
| BOSCH | 0 986 479 191 |
| BREMBO | 08.9826.10 |
| LETEC | LBG041S |
| ROAD HOUSE | 6789.00 |
| SANLI | SL10886 |
| TRW | DF4344 |
| Vehicle | Engine | Fuel | Date | CC | KW | CV | Traction |
|---|---|---|---|---|---|---|---|
| 1.8 | 1 | 03/2003-07/2012 | 1796 | 82 | 111 | 1 | |
| 1.8 Flex (75) | 19 | 09/2005-07/2012 | 1796 | 84 | 114 | 1 |
| Vehicle | Engine | Fuel | Date | CC | KW | CV | Traction |
|---|---|---|---|---|---|---|---|
| 1.4 (L67) |
Z 14 XEP |
1 | 10/2005-10/2010 | 1364 | 66 | 90 | 1 |
| Vehicle | Engine | Fuel | Date | CC | KW | CV | Traction |
|---|---|---|---|---|---|---|---|
| 1.4 16V |
Z 14 XEP |
1 | 08/2005- | 1364 | 66 | 90 | 1 |
| 1.6 |
Z 16 SE |
1 | 10/2001- | 1598 | 64 | 87 | 1 |
| 1.6 CNG 16V |
Z 16 YNG |
16 | 06/2006- | 1598 | 69 | 94 | 1 |
| 1.6 CNG 16V |
Z 16 YNG |
16 | 04/2005- | 1598 | 71 | 97 | 1 |
| 1.3 CDTI 16V |
Z 13 DT |
2 | 08/2005- | 1248 | 51 | 69 | 1 |
| 1.3 CDTI 16V |
Z 13 DTJ |
2 | 10/2005-12/2012 | 1248 | 55 | 75 | 1 |
| 1.7 DI 16V |
Y 17 DTL |
2 | 10/2001- | 1686 | 48 | 65 | 1 |
| 1.7 DTI 16V |
Y 17 DT |
2 | 10/2001- | 1686 | 55 | 75 | 1 |
| Vehicle | Engine | Fuel | Date | CC | KW | CV | Traction |
|---|---|---|---|---|---|---|---|
| 1.4 |
Z 14 XEP |
1 | 10/2004-12/2011 | 1364 | 66 | 90 | 1 |
| 1.6 | 1 | 10/2001-09/2006 | 1598 | 62 | 84 | 1 | |
| 1.6 |
Z 16 SE |
1 | 10/2001-09/2006 | 1598 | 64 | 87 | 1 |
| 1.6 CNG |
Z 16 YNG |
16 | 06/2006-12/2011 | 1598 | 69 | 94 | 1 |
| 1.6 CNG |
Z 16 YNG |
16 | 04/2005-01/2011 | 1598 | 71 | 97 | 1 |
| 1.3 CDTI 16V |
Y 13 DT Z 13 DT |
2 | 06/2004-01/2011 | 1248 | 51 | 69 | 1 |
| 1.3 CDTI 16V |
Z 13 DTJ |
2 | 10/2005-12/2011 | 1248 | 55 | 75 | 1 |
| 1.7 DI 16V |
Y 17 DTL |
2 | 10/2001-06/2004 | 1686 | 48 | 65 | 1 |
| 1.7 DTI 16V |
Y 17 DT |
2 | 10/2001-06/2004 | 1686 | 55 | 75 | 1 |
| Vehicle | Engine | Fuel | Date | CC | KW | CV | Traction |
|---|---|---|---|---|---|---|---|
| 1.6 (F08, F68) | 1 | 09/2000-12/2009 | 1598 | 62 | 84 | 1 | |
| 1.8 (F08, F68) |
Z 18 XEL |
1 | 01/2002-12/2009 | 1796 | 79 | 107 | 1 |
| Vehicle | Engine | Fuel | Date | CC | KW | CV | Traction |
|---|---|---|---|---|---|---|---|
| 1.6 (E75) |
Z 16 XEP |
1 | 01/2006-05/2010 | 1598 | 77 | 105 | 1 |
| 1.6 16V (E75) |
Z 16 XE |
1 | 05/2003-01/2006 | 1598 | 74 | 100 | 1 |
| 1.8 (E75) |
Z 18 XE |
1 | 05/2003-05/2010 | 1796 | 92 | 125 | 1 |
| 1.3 CDTI (E75) |
Y 13 DT Z 13 DT |
2 | 04/2005-05/2010 | 1248 | 51 | 69 | 1 |
| 1.3 CDTI (E75) |
Z 13 DTJ |
2 | 09/2003-05/2010 | 1248 | 55 | 75 | 1 |
| 1.7 DTI (E75) |
Y 17 DT |
2 | 09/2003-05/2010 | 1686 | 55 | 75 | 1 |
| Vehicle | Engine | Fuel | Date | CC | KW | CV | Traction |
|---|---|---|---|---|---|---|---|
| 1.4 16V |
Z 14 XE |
1 | 10/2001-05/2007 | 1389 | 66 | 90 | 1 |
| 1.4 i 16V |
Z 14 XEP |
1 | 01/2004-11/2011 | 1364 | 66 | 90 | 1 |
| 1.6 |
Z 16 SE |
1 | 09/2001-10/2004 | 1598 | 62 | 84 | 1 |
| 1.6 |
Z 16 SE |
1 | 10/2001-11/2011 | 1598 | 64 | 87 | 1 |
| 1.6 CNG 16V |
Y 16 YNG Z 16 YNG |
16 | 06/2006-02/2012 | 1598 | 69 | 94 | 1 |
| 1.6 CNG 16V |
Z 16 YNG |
16 | 04/2005-02/2012 | 1598 | 71 | 97 | 1 |
| 1.3 CDTI 16V |
Y 13 DT Z 13 DT |
2 | 09/2004-02/2012 | 1248 | 51 | 69 | 1 |
| 1.3 CDTI 16V |
Z 13 DTJ |
2 | 10/2005-11/2011 | 1248 | 55 | 75 | 1 |
| 1.7 DI 16V |
Y 17 DTL |
2 | 09/2001-11/2011 | 1686 | 48 | 65 | 1 |
| 1.7 DTI 16V |
Y 17 DT |
2 | 10/2001-11/2011 | 1686 | 55 | 75 | 1 |
| Vehicle | Engine | Fuel | Date | CC | KW | CV | Traction |
|---|---|---|---|---|---|---|---|
| 1.4 |
Z 14 XEP |
1 | 10/2004-09/2010 | 1364 | 66 | 90 | 1 |
| 1.6 |
Z 16 SE |
1 | 10/2001-06/2004 | 1598 | 64 | 87 | 1 |
| 1.6 CNG |
Z 16 YNG |
16 | 06/2006-09/2010 | 1598 | 69 | 94 | 1 |
| 1.6 CNG |
Z 16 YNG |
16 | 04/2005-02/2012 | 1598 | 71 | 97 | 1 |
| 1.3 CDTI 16V |
Z 13 DT |
2 | 09/2004-09/2006 | 1248 | 51 | 69 | 1 |
| 1.3 CDTI 16V |
Z 13 DTJ |
2 | 07/2006-02/2012 | 1248 | 55 | 75 | 1 |
| 1.7 DI 16V |
Y 17 DTL |
2 | 09/2001-06/2004 | 1686 | 48 | 65 | 1 |
| 1.7 DTI 16V |
Y 17 DT |
2 | 10/2001-02/2012 | 1686 | 55 | 75 | 1 |
| Vehicle | Engine | Fuel | Date | CC | KW | CV | Traction |
|---|---|---|---|---|---|---|---|
| 1.4 Twinport (F08, F68) |
Z 14 XEP |
1 | 06/2003-10/2006 | 1364 | 66 | 90 | 1 |
| Vehicle | Engine | Fuel | Date | CC | KW | CV | Traction |
|---|---|---|---|---|---|---|---|
| 1.7 DI 16V (F08) |
Y 17 DTL |
2 | 09/2000-06/2006 | 1686 | 48 | 65 | 1 |
| 1.7 DTI 16V (F08) |
Y 17 DT |
2 | 09/2000-06/2006 | 1686 | 55 | 75 | 1 |
| Vehicle | Engine | Fuel | Date | CC | KW | CV | Traction |
|---|---|---|---|---|---|---|---|
| 1.6 i 16V |
Z 16 XE |
1 | 01/2003-09/2005 | 1598 | 74 | 100 | 1 |
| 1.6 i 16V Twinport |
Z 16 XEP |
1 | 05/2003-06/2010 | 1598 | 77 | 105 | 1 |
| 1.8 i 16V |
Z 18 XE |
1 | 05/2003-06/2010 | 1796 | 92 | 125 | 1 |
| 1.3 CDTi |
Y 13 DT Z 13 DT |
2 | 04/2005-06/2010 | 1248 | 51 | 69 | 1 |
| 1.3 CDTi |
Z 13 DTJ |
2 | 01/2003-10/2009 | 1248 | 55 | 75 | 1 |
| 1.7 DTI |
Y 17 DT |
2 | 06/2003-06/2010 | 1686 | 55 | 75 | 1 |
