Product 78BD9197-2

Description: Brake disc
Axe: Front
No. of Pieces: 2
Barcode: 8424073149404
Url: https://catalogonuevo.icerbrakes.com/Producto/Details?idProducto=78BD9197-2
Weight (gr.): 20432

Measures: Ø345x28x54.6
: Brake Disc Type: Vented; Minimum thickness [mm]: 26.5; Hole Arrangement/Number: 5; Bolt Hole Circle Ø [mm]: 115; Wheel Hub Diameter [mm]: 72.5

Reference applications

Brand	OE Reference
CHRYSLER	4779197AB
CHRYSLER	4779197AC
CHRYSLER	4779197AD
CHRYSLER	4779197AE
CHRYSLER	4779197AF
CHRYSLER	4779197AG
CHRYSLER	5154118AA
CHRYSLER	5154118AB
CHRYSLER	5154118AC
DODGE	4779197AA
LANCIA	K04779197AE
LANCIA	K04779197AF
LANCIA	K04779197AG
LANCIA	K05154118AB
LANCIA	K05154118AC
LANCIA	K05154118AD

Maker	Cross reference
BREMBO	09.A404.10
BREMBO	09.A404.1X
DELPHI LOCKHEED	BG9050
DELPHI LOCKHEED	BG9050C
FERODO	DDF1765
GIRLING	6062445
HELLA-PAGID	8DD 355 115-471
LETEC	LBU013V
MINTEX	MDC1928
ROAD HOUSE	61269.10
SANLI	SL34225
TEXTAR	92177105
TEXTAR	98200 1771 0 1
TRW	DF6244S

CHRYSLER

300 (U.S.A.) Saloon 09/2004-12/2011

Vehicle	Engine	Fuel	Date	CC	KW	CV	Traction
5.7		1	09/2004-12/2007		254	345	1

300 C (LX, LE) Saloon 09/2004-

Vehicle	Engine	Fuel	Date	CC	KW	CV	Traction
2.7	EES	1	01/2007-11/2012	2736	130	177	2
2.7		1	09/2009-12/2010	2736	133	181	1
2.7	EER	1	09/2004-11/2012	2736	142	193	2
3.5	EGG	1	09/2004-11/2012	3518	183	249	2
3.5		1	01/2005-12/2010	3518	186	253	2
3.5 AWD	EGG	1	09/2004-12/2010	3518	186	253	3
5.7	EZB EZD EZH	1	09/2004-12/2008	5654	250	340	2
5.7		1	09/2004-08/2008	5654	250	340	1
5.7		1	12/2009-11/2012	5654	256	348	1
5.7	EZH	1	05/2009-12/2010	5654	265	360	2
5.7	EZH	1	09/2008-	5654	268	364	2
5.7 AWD	EZD	1	09/2008-	5654	268	364	3
6.1 SRT8	ESF	1	06/2005-11/2012	6059	317	431	2
3.0 CRD	EXL	2	09/2005-11/2012	2987	160	218	2

300 C Touring (LX, LE) Estate 09/2004-12/2010

Vehicle	Engine	Fuel	Date	CC	KW	CV	Traction
2.7	EES	1	01/2007-12/2010	2736	130	177	2
2.7	EER	1	09/2004-12/2010	2736	142	193	2
3.5	EGG	1	09/2004-12/2010	3518	183	249	2
3.5 AWD	EGG	1	09/2004-12/2010	3518	183	249	3
5.7	EZB EZD EZH	1	09/2004-12/2010	5654	250	340	2
5.7 AWD	EZB EZH	1	04/2005-12/2010	5654	250	340	3
6.1 SRT8	ESF	1	06/2005-12/2010	6059	317	431	2
3.0 CRD	EXL	2	09/2005-12/2010	2987	160	218	2

300 C II (LX) Saloon 09/2010-

Vehicle	Engine	Fuel	Date	CC	KW	CV	Traction
3.6	ERB	1	09/2011-	3604	210	286	2
3.6	ERB	1	07/2011-	3604	215	292	2
3.6		1	04/2015-	3604	216	294	2
3.6	ERB	1	01/2011-	3604	218	296	2
3.6 AWD	ERB	1	12/2012-	3604	210	286	3
3.6 AWD	ERB	1	01/2012-	3604	215	292	3
5.7	EZH	1	09/2010-	5654	271	369	2
5.7 AWD		1	09/2010-	5654	271	369	3
6.4	ESG	1	09/2011-	6417	347	472	2
6.4		1	01/2012-	6424	401	545	1
6.4 SRT8	ESG	1	09/2011-	6417	350	476	2
3.6 Flexfuel	ERB	19	09/2010-	3604	218	296	2
3.0 CRD	EXF	2	09/2011-	2987	176	239	2

CHRYSLER (BBDC)

300C () Saloon 10/2006-01/2012

Vehicle	Engine	Fuel	Date	CC	KW	CV	Traction
2.7		1	10/2006-	2736	152	204	1
3.5		1	10/2006-	3518	189	253	1
5.7		1	10/2006-	5654	252	338	1

DODGE

CHALLENGER III () Coupe 09/2007-

Vehicle	Engine	Fuel	Date	CC	KW	CV	Traction
3.6	ERB	1	01/2011-	3604	227	309	2
6.4	ESG ESH	1	09/2014-	6417	362	492	2
6.4 SRT8	ESH	1	08/2011-	6417	346	471	2
6.4 SRT8	ESG	1	01/2011-	6417	351	477	2

CHARGER VI () Saloon 06/2005-12/2010

Vehicle	Engine	Fuel	Date	CC	KW	CV	Traction
3.5 AWD	EGG	1	09/2006-12/2010	3518	186	253	3
6.1 SRT8	ESF	1	09/2005-12/2010	6059	317	431	2

CHARGER VII () Saloon 09/2010-

Vehicle	Engine	Fuel	Date	CC	KW	CV	Traction
3.6	ERB	1	06/2012-	3604	215	292	2
3.6	ERB	1	01/2011-	3604	218	296	2
3.6 AWD	ERB	1	01/2011-	3605	218	296	3
5.7	EZH	1	06/2012-	5654	272	370	2
5.7 R/T	EZH	1	09/2010-	5654	276	375	2
5.7 R/T AWD	EZH	1	09/2010-	5654	276	375	3
6.2 SRT Hellcat	ESD	1	09/2014-	6166	527	717	2
6.4 SRT8	ESG	1	09/2011-	6417	351	477	2
6.4 SRT8	ESG	1	09/2014-	6417	362	492	2
5.7 Flexfuel	EZH	19	09/2010-12/2014	5654	276	375	2
5.7 Flexfuel AWD	EZH	19	09/2010-12/2014	5654	276	375	3

LANCIA

THEMA II (LX_) Saloon 09/2011-

Vehicle	Engine	Fuel	Date	CC	KW	CV	Traction
3.6 (48, LX)	ERB	1	09/2011-10/2014	3604	210	286	2
3.6 4WD (LX, 48)	ERB	1	09/2011-10/2014	3604	210	286	3
3.0 D (48, LX)	EXF	2	09/2011-10/2014	2987	176	239	2
3.0 D (LX, 48)	EXF	2	09/2011-10/2014	2987	140	190	2
