Product 78CV0044-1
- Description
- Brake disc for Commercial Vehicle
- Axe
- Front-Rear
- No. of Pieces
- 1
- Barcode
-
8424073294272
- Url
- https://catalogonuevo.icerbrakes.com/Producto/Details?idProducto=78CV0044-1
- Weight (gr.)
- 17000
- Measures
- Ø335x34x93
-
Brake Disc Type:
Vented -
Minimum thickness [mm]:
26 -
Hole Arrangement/Number:
10 -
Bolt Hole Circle Ø [mm]:
122 -
Wheel Hub Diameter [mm]:
90
| Brand | OE Reference |
|---|---|
| MAN | 81508030042 |
| MAN | 81508030053 |
| Maker | Cross reference |
|---|---|
| BREMBO | 09.B564.10 |
| FERODO | FCR330A |
| ROAD HOUSE | NSX1173.20 |
| TEXTAR | 93138000 |
| Vehicle | Engine | Fuel | Date | CC | KW | CV | Tonnage | Axels |
|---|---|---|---|---|---|---|---|---|
| 10.180 |
D 0834 LFL 41 D 0834 LFL 51 D 0834 LFL 54 D 0834 LFL 64 |
2 | 04/2005-03/2022 | 4580 | 132 | 180 | 10.00 | 4x2 |
| 10.210 |
D 0834 LFL 42 D 0834 LFL 52 D 0834 LFL 55 |
2 | 04/2005-03/2022 | 4580 | 151 | 206 | 10.00 | 4x2 |
| 10.220 |
D 0834 LFL 65 D 0834 LFL 68 |
2 | 04/2005-03/2022 | 4580 | 162 | 220 | 10.00 | 4x2 |
| 10.240 |
D 0836 LFL 40 D 0836 LFL 50 D 0836 LFL 53 |
2 | 04/2005-03/2022 | 6871 | 176 | 240 | 10.00 | 4x2 |
| 10.250 |
D 0836 LFL 63 D 0836 LFL 66 |
2 | 04/2005-03/2022 | 6871 | 184 | 250 | 10.00 | 4x2 |
| 12.180 |
D 0834 LFL 41 D 0834 LFL 51 D 0834 LFL 54 D 0834 LFL 64 |
2 | 04/2005-03/2022 | 4580 | 132 | 180 | 11.00 | 4x2 |
| 12.210 |
D 0834 LFL 42 D 0834 LFL 52 D 0834 LFL 55 |
2 | 04/2005-03/2022 | 4580 | 151 | 206 | 11.00 | 4x2 |
| 12.220 |
D 0834 LFL 65 D 0834 LFL 68 |
2 | 04/2005-03/2022 | 4580 | 162 | 220 | 12.00 | 4x2 |
| 12.240 |
D 0836 LFL 40 D 0836 LFL 50 D 0836 LFL 53 |
2 | 04/2005-03/2022 | 6871 | 176 | 240 | 11.00 | 4x2 |
| 12.250 |
D 0836 LFL 63 D 0836 LFL 66 |
2 | 04/2005-03/2022 | 6871 | 184 | 250 | 12.00 | 4x2 |
| 7.150, 8.150 |
D 0834 LFL 40 D 0834 LFL 50 D 0834 LFL 53 D 0834 LFL 60 D 0834 LFL 63 D 0834 LFL 66 |
2 | 04/2005-03/2022 | 4580 | 110 | 150 | 7.00 | 4x2 |
| 7.180, 8.180 |
D 0834 LFL 41 D 0834 LFL 51 D 0834 LFL 54 D 0834 LFL 61 D 0834 LFL 64 |
2 | 04/2005-03/2022 | 4580 | 132 | 180 | 7.00 | 4x2 |
| 8.180 |
D 0834 LFL 41 D 0834 LFL 51 D 0834 LFL 54 D 0834 LFL 64 D 0834 LFL 67 |
2 | 04/2005-03/2022 | 4580 | 132 | 180 | 8.00 | 4x2 |
| 8.210 |
D 0834 LFL 42 D 0834 LFL 52 D 0834 LFL 55 |
2 | 04/2005-03/2022 | 4580 | 151 | 206 | 8.00 | 4x2 |
| 8.220 |
D 0834 LFL 65 D 0834 LFL 68 |
2 | 04/2005-03/2022 | 4580 | 162 | 220 | 8.00 | 4x2 |
| 8.240 |
D 0836 LFL 40 D 0836 LFL 50 D 0836 LFL 53 |
2 | 04/2005-03/2022 | 6871 | 176 | 240 | 8.00 | 4x2 |
| 8.250 |
D 0836 LFL 63 D 0836 LFL 66 |
2 | 04/2005-03/2022 | 6871 | 184 | 250 | 8.00 | 4x2 |
| Vehicle | Engine | Fuel | Date | CC | KW | CV | Tonnage | Axels |
|---|---|---|---|---|---|---|---|---|
| 10.180 |
D 0834 LFL 41 D 0834 LFL 51 D 0834 LFL 54 D 0834 LFL 64 D 0834 LFL 67 |
2 | 04/2005-03/2022 | 4580 | 132 | 180 | 10.00 | 4x2 |
| 10.210 |
D 0834 LFL 42 D 0834 LFL 52 D 0834 LFL 55 |
2 | 04/2005-03/2022 | 4580 | 151 | 206 | 10.00 | 4x2 |
| 10.220 |
D 0834 LFL 65 D 0834 LFL 68 |
2 | 04/2005-03/2022 | 4580 | 162 | 220 | 10.00 | 4x2 |
| 10.240 |
D 0836 LFL 40 D 0836 LFL 50 D 0836 LFL 53 |
2 | 04/2005-03/2022 | 6871 | 176 | 240 | 10.00 | 4x2 |
| 10.250 |
D 0836 LFL 63 D 0836 LFL 66 |
2 | 04/2005-03/2022 | 6871 | 184 | 250 | 10.00 | 4x2 |
| 12.180 |
D 0834 LFL 41 D 0834 LFL 51 D 0834 LFL 54 D 0834 LFL 64 D 0834 LFL 67 |
2 | 04/2005-03/2022 | 4580 | 132 | 180 | 11.00 | 4x2 |
| 12.210 |
D 0834 LFL 42 D 0834 LFL 52 D 0834 LFL 55 |
2 | 04/2005-03/2022 | 4580 | 151 | 206 | 11.00 | 4x2 |
| 12.220 |
D 0834 LFL 65 D 0834 LFL 68 |
2 | 04/2005-03/2022 | 4580 | 162 | 220 | 12.00 | 4x2 |
| 12.240 |
D 0836 LFL 40 D 0836 LFL 50 D 0836 LFL 53 |
2 | 04/2005-03/2022 | 6871 | 176 | 240 | 11.00 | 4x2 |
| 12.250 |
D 0836 LFL 63 D 0836 LFL 66 |
2 | 04/2005-03/2022 | 6871 | 184 | 250 | 12.00 | 4x2 |
| 7.150 | 2 | 01/2004-03/2022 | 4580 | 110 | 150 | 7.00 | 4x2 | |
| 7.180 | 2 | 01/2004-03/2022 | 4580 | 132 | 179 | 7.00 | 4x2 | |
| 8.150 |
D 0834 LFL 40 D 0834 LFL 50 D 0834 LFL 53 D 0834 LFL 63 D 0834 LFL 66 |
2 | 10/2006-03/2022 | 4580 | 110 | 150 | 7.00 | 4x2 |
| 8.180 |
D 0834 LFL 41 D 0834 LFL 51 D 0834 LFL 54 D 0834 LFL 64 D 0834 LFL 67 |
2 | 04/2005-03/2022 | 4580 | 132 | 180 | 8.00 | 4x2 |
| 8.210 |
D 0834 LFL 42 D 0834 LFL 52 D 0834 LFL 55 |
2 | 04/2005-03/2022 | 4580 | 151 | 206 | 8.00 | 4x2 |
| 8.220 |
D 0834 LFL 65 D 0834 LFL 68 |
2 | 04/2005-03/2022 | 4580 | 162 | 220 | 8.00 | 4x2 |
| 8.240 |
D 0836 LFL 40 D 0836 LFL 50 D 0836 LFL 53 |
2 | 04/2005-03/2022 | 6871 | 176 | 240 | 8.00 | 4x2 |
| 8.250 |
D 0836 LFL 63 D 0836 LFL 66 |
2 | 04/2005-03/2022 | 6871 | 184 | 250 | 8.00 | 4x2 |
| Vehicle | Engine | Fuel | Date | CC | KW | CV | Tonnage | Axels |
|---|---|---|---|---|---|---|---|---|
| 10.180 | 2 | 08/2012-03/2022 | 4580 | 132 | 179 | 10.00 | 4x2 | |
| 10.220 | 2 | 08/2012-03/2022 | 4580 | 162 | 220 | 10.00 | 4x2 | |
| 10.250 | 2 | 04/2008-03/2022 | 6871 | 184 | 250 | 10.00 | 4x2 | |
| 12.180 | 2 | 08/2012-03/2022 | 4580 | 132 | 179 | 11.00 | 4x2 | |
| 12.220 | 2 | 08/2012-03/2022 | 4580 | 162 | 220 | 11.00 | 4x2 | |
| 12.250 | 2 | 04/2008-03/2022 | 6871 | 184 | 250 | 11.00 | 4x2 | |
| 7.180 | 2 | 08/2012-03/2022 | 4580 | 132 | 179 | 7.00 | 4x2 | |
| 8.180 | 2 | 08/2012-03/2022 | 4580 | 132 | 179 | 7.00 | 4x2 | |
| 8.220 | 2 | 08/2012-03/2022 | 4580 | 162 | 220 | 7.00 | 4x2 | |
| 8.250 | 2 | 04/2008-03/2022 | 6871 | 184 | 250 | 7.00 | 4x2 |
